Vertiv 1500VA 1350W Line-Interactive Rackmount UPS

When the power cuts out, the Vertiv 1500VA keeps your rack running at up to 1350W — long enough to save work and shut down safely.

The Vertiv Edge uninterruptible power supply (UPS) is designed to protect server and networking equipment in distributed and Edge IT applications. With 2U convertible rack/tower format, this 1500VA UPS offers reliable protection from downtime and damage caused by power spikes, swells and brownouts. Automatic Voltage Regulation (AVR) extends battery life and safeguards critical equipment. With sine wave output, this line interactive UPS ensures availability of network closets and Edge data centers. It operates at up to 98% efficiency in normal operation mode, providing energy savings. Add optional Vertiv Intellislot SNMP/Webcards for remote power management and OS's shutdown with free Vertiv Power Assist software. The Edge family has a wide range of power ratings, from 500VA up to 3000VA and form factors, such as mini-tower, 1U rack and rack/tower. It is easy to install, configure and operate and comes with an intuitive, color LCD screen.

Specifications

Power
Output power	1350 W
Input operation voltage (max)	278 V
Output operation voltage (min)	200 V
Output operation voltage (max)	240 V
Output power capacity	1.5 kVA
Performance
UPS topology	Line-Interactive
Waveform	Pure sine
Features
Country of origin	China
Ports & interfaces
USB port	Yes
AC outlets quantity	6 AC outlet(s)
AC outlet types	C13 coupler
Design
Rack capacity	2U
Form factor	Rackmount/Tower
Product colour	Black
Safety	EN60020-1:2008+A1:2013
Display type	LCD
Operational conditions
Operating temperature (T-T)	0 - 40 °C
Operating altitude	0 - 3000 m
Technical details
Harmonized System (HS) code	85078000
Compliance certificates	RoHS
Weight & dimensions
Weight	20 kg
Width	438 mm
Height	88 mm
Depth	510 mm

Downloads

• Datasheet (PDF)
• Product manual / brochure (PDF)
