TP-LINK EAP245 Access Point PoE

with simple central management.

Superior Wi-Fi Speeds and Performance
QCA enterprise class chipsets, dedicated high-power amplifier and professional antenna along with the latest generation 802.11ac Wave 2 MU-MIMO technology, ensure superior 1750 Mbps Wi-Fi speeds and long-range coverage over 2.4GHz and 5GHz wireless bands.

Seamless Roaming
802.11k/802.11v seamless roaming switches clients automatically to the access point with the optimal signal with a seamless transition when moving. This allows sensitive applications like VoIP and video conferences to go uninterrupted.

Secure Guest Network with Facebook Wi-Fi and SMS Login
Guest Network provides secure access to guests sharing your Wi-Fi network, with captive portal helping maintain only authorized guests to use the network. The addition of SMS and Facebook authentication simplifies the captive portal even further to simplify connectivity and boost your business.

Multiple PoE Options for Easy Installation
EAP245 supports both 802.3af PoE and Passive PoE power supply, can be either powered by a PoE switch or the provided PoE adapter. The addition of elegant appearance and simple mounting design for easy attachment to a wall or ceiling further makes deployment effortless and flexible.

Cloud Centralized Management
- Anytime, Anywhere
Omada Hardware Controller OC200 and Omada Software Controller make it easy to manage and monitor the whole Omada network in real-time, while cloud service enables remote and secure access no matter where you find yourself.

Easy Management with the Omada App
Follow configuration instructions on the free Omada app to get set up in minutes. Omada lets you configure settings, monitor the network status and manage clients, all from the convenience of a smartphone or tablet.

Meet Our New Hero Product!
The OC200 Omada Hardware Controller is dedicated to providing centralized management for the whole Omada network.

Omada Hardware Controller

Specifications

Data transmission
Ethernet LAN data rates	10,100,1000 Mbit/s
Maximum data transfer rate	1300 Mbit/s
Performance
2.4 GHz	Yes
5 GHz	Yes
Wireless isolation	Yes
Automatic channel selection	Yes
Syslog	Yes
Transmitting power	27 dBmW
Reset button	Yes
Frequency band	2.4, 5 GHz
Web-based management	Yes
Rate limiting	Yes
Quality of Service (QoS) support	Yes
Networking standards	IEEE 802.11a, IEEE 802.11ac, IEEE 802.11b, IEEE 802.11g, IEEE 802.11n, IEEE 802.1x, IEEE 802.3af
Certification	CE, FCC, RoHS
MIMO type	Multi User MIMO
MIMO	Yes
Airtime Fairness (ATF)	Yes
Compatible operating systems	Microsoft Windows XP, Windows Vista, Windows 7, Windows 8, Windows 10
Security
Cable lock slot	Yes
Port-based Network Access Control (PNAC)	Yes
Number of SSID supported	16
Security algorithms	64-bit WEP, 128-bit WEP, 152-bit WEP, WPA, WPA-PSK, WPA2, WPA2-PSK
MAC address filtering	Yes
Access Control List (ACL)	Yes
Features
Maximum data transfer rate (2.4 GHz)	450 Mbit/s
Maximum data transfer rate (5 GHz)	1300 Mbit/s
Virtual LAN features	SSID-based VLAN assignment
Ports & interfaces
USB 2.0 ports quantity	0
Ethernet LAN (RJ-45) ports	2
DC-in jack	Yes
Power
Power consumption (typical)	12.3 W
Power over Ethernet (PoE)	Yes
Input current	1.5 A
AC input voltage	12 V
Design
Placement	Ceiling, Wall
Product colour	White
LED indicators	Power
Cable lock slot type	Kensington
Antenna
Antenna type	Internal
Antenna gain level (max)	4 dBi
Antenna direction type	Omni-directional
Antenna features	Integrated antenna
Technical details
Harmonized System (HS) code	85176990
Weight & dimensions
Width	205.4 mm
Depth	181.6 mm
Height	37.4 mm
Packaging data
Quick start guide	Yes
Mounting kit	Yes
PoE adapter included	Yes
Operational conditions
Operating relative humidity (H-H)	10 - 90%
Operating temperature (T-T)	0 - 40 °C
Storage temperature (T-T)	-40 - 70 °C
Storage relative humidity (H-H)	5 - 90%
