TP-LINK Archer AC1200 Networking
TP-LINK Archer AC1200 Networking
Regular price
£75.42 GBP
Regular price
Sale price
£75.42 GBP
Taxes included.
Quantity
Couldn't load pickup availability
The TP-LINK Archer AC1200 is a dependable addition to any modern network installation.
4G LTE with AC1200 Wi-Fi to Stream from EverywhereAC1200 Wireless Dual Band 4G LTE Router
Archer MR400
Got SIM Card?
Then Plug and Play!
With an integrated 4G LTE modem and a built-in SIM card slot, all you need to do is insert a micro SIM card and turn on the Router. Enjoying fast, stable Wi-Fi on a 4G LTE network has never been easier.
Share Your 4G LTE Network
Take full of advantage of your cutting-edge 4G LTE network for download speeds of up to 150 Mbps. Share your 4G LTE network with multiple Wi-Fi devices and enjoy uninterrupted HD movies, rapid file downloads, and smooth video chats. Fully compatible with FDD-LTE and TDD-LTE to work with most service providers worldwide.
Wi-Fi Where You Need It
Enjoy unmatched convenience and versatility. Tested in the field for years to ensure universal compatibility with 2 advanced LTE antennas to deliver a smooth connection. Simply plug in a micro SIM card and power on this elegant piece of technology to utilize fast and stable Wi-Fi, whether you’re at home or working remote.
Internet Access for
up to 64 Devices Simultaneously
Easily share a 3G/4G connection with up to 64 wireless devices, such as phones, tablets, and laptops, at the same time. 4 LAN ports stand ready to provide internet for wired devices like desktop computers.
Easy Setup and Management
Set up the Archer MR400 in minutes thanks to its intuitive web interface and the powerful Tether app. Tether also lets you manage its network settings from any Android or iOS device, including parental controls and access control.
Specifications
| Ethernet LAN features | |
|---|---|
| Ethernet WAN | Yes |
| Ethernet LAN interface type | Fast Ethernet |
| Ethernet LAN | Yes |
| Ethernet LAN data rates | 10,100 Mbit/s |
| Cabling technology | 10/100Base-T(X) |
| DSL features | |
| DSL WAN | No |
| Mobile network | |
| SIM card slot | Yes |
| 3G/4G USB modem compatibility | No |
| Mobile network generation | 4G |
| 3G | Yes |
| 4G | Yes |
| GSM bands supported | 850,900,1800,1900 MHz |
| 4G bands supported | 800,900,1800,2100,2600 MHz |
| 2G standards | Edge, GPRS, GSM |
| 3G standards | DC-HSPA+, HSPA, HSPA+, UMTS |
| 4G standard | LTE |
| SIM card type | MicroSIM |
| 3G bands supported | 900,2100 MHz |
| Network | |
| Guest access | Yes |
| VPN tunnels quantity | 10 |
| VPN support | PPTP, L2TP, IPSec |
| Receiver sensitivity | 5GHz: 11a 54M: -74dBm 11ac HT20: -67dBm 11ac HT40: -64dBm 11ac HT80 : -60dBm 11n HT20: -71dBm 11n HT40: -70dBm 2.4G: 11g 54M: -76dBm 11n HT20: -73dBm 11n HT40: -67dBm |
| Port forwarding | Yes |
| Networking standards | IEEE 802.11a, IEEE 802.11ac, IEEE 802.11b, IEEE 802.11g, IEEE 802.11n |
| VPN server | PPTP VPN, IPSec VPN , OpenVPN |
| VPN Passthrough | Yes |
| Dynamic DNS (DDNS) | Yes |
| Protocols | |
| DMZ support | Yes |
| Universal Plug and Play (UPnP) | Yes |
| Supported network protocols | IPv4, IPv6 |
| DHCP server | Yes |
| DHCP client | Yes |
| Management features | |
| WPS push button | Yes |
| Web-based management | Yes |
| Reset button | Yes |
| Quality of Service (QoS) support | Yes |
| Security | |
| Security algorithms | 64-bit WEP, 128-bit WEP, WPA, WPA-PSK, WPA2, WPA2-PSK |
| Firewall security | DoS, SPI Firewall, IP and MAC Address Binding |
| Firewall | Yes |
| DoS attack prevention | Yes |
| Stateful Packet Inspection (SPI) | Yes |
| Access Control List (ACL) | Yes |
| Performance | |
| Windows operating systems supported | Windows 10, Windows 2000, Windows 7, Windows 8, Windows 8.1, Windows 98SE, Windows NT, Windows Vista, Windows XP Home, Windows XP Home x64, Windows XP Professional, Windows XP Professional x64 |
| Mac operating systems supported | macOS |
| Linux operating systems supported | Yes |
| Memory card slot(s) | No |
| Weight & dimensions | |
| Package width | 307 mm |
| Package weight | 670 g |
| Package height | 70 mm |
| Package depth | 223 mm |
| Width | 174 mm |
| Height | 33.5 mm |
| Depth | 124.5 mm |
| Packaging content | |
| Package type | Box |
| Cables included | LAN (RJ-45) |
| AC adapter included | Yes |
| Quick installation guide | Yes |
| WAN connection | |
| WAN connection type | RJ-45 |
| Wireless LAN features | |
| Top Wi-Fi standard | Wi-Fi 5 (802.11ac) |
| WLAN data transfer rate (max) | 867 Mbit/s |
| Wi-Fi band | Dual-band (2.4 GHz / 5 GHz) |
| WLAN data transfer rate (first band) | 450 Mbit/s |
| WLAN data transfer rate (second band) | 867 Mbit/s |
| Wi-Fi standards | 802.11a, Wi-Fi 5 (802.11ac), 802.11b, 802.11g, Wi-Fi 4 (802.11n) |
| Ports & interfaces | |
| USB port | No |
| Ethernet LAN (RJ-45) ports | 3 |
| DC-in jack | Yes |
| Design | |
| Product type | Tabletop router |
| Wall mountable | Yes |
| On/off switch | Yes |
| LED indicators | LAN, Power, Status, WLAN |
| Product colour | Black |
| Certificates | |
| Certification | CE, RoHS |
| Software | |
| Mac compatibility | Yes |
| Antenna | |
| Antenna design | Internal & external |
| Detachable antenna(s) | Yes |
| Antennas quantity | 2 |
| Transmit power | CE: <20dBm(2.4GHz), <23dBm(5GHz) |
| Features | |
| Harmonized System (HS) code | 85176990 |
| Power | |
| Power source type | DC |
| Output voltage | 12 V |
| Output current | 1.5 A |
| Operational conditions | |
| Storage temperature (T-T) | -40 - 70 °C |
| Storage relative humidity (H-H) | 5 - 90% |
| Operating temperature (T-T) | 0 - 40 °C |
| Operating relative humidity (H-H) | 10 - 90% |
