StarTech.com Single-Mode (SM) SC Fiber Media Converter for 10/100/1000 Networks, Standalone Gigabit Ethernet to SC Fiber Converter, 1310nm, 10km - TAA Networking

The StarTech.com Single-Mode (SM) SC Fiber Media Converter for 10/100/1000 Networks, Standalone Gigabit Ethernet to SC Fiber Converter, 1310nm, 10km - TAA is a dependable addition to any modern network installation.

Convert and extend a Gigabit Ethernet connection up to 10 km over single-mode SC fiber

This fiber media converter converts and extends a Gigabit Ethernet (1000 Mbps) network up to 10 km over single-mode fiber on 1000BASE-LX networks.

Extend your GbE network cost-effectively

The fiber media converter provides a cost-effective way to transparently convert copper to fiber, or fiber to copper, for connecting remote sub-networks to larger fiber-optic networks. Providing both SC fiber and RJ45 Ethernet ports, it integrates easily into a wide range of Gigabit Ethernet network infrastructures. The RJ45 port supports triple-speed (10/100/1000 BASE-T) auto-negotiation.

Reliable and scalable network connectivity

Supporting a maximum single-mode fiber cable distance of up to 10 km (6.2 mi.), the media converter delivers a simple and reliable solution for connecting Gigabit Ethernet networks to remote locations, while ensuring solid network performance. It provides optimum network scalability for connecting two or more Ethernet network nodes, for instance, connecting two buildings on the same campus or facility. The media converter also delivers high-speed bandwidth to meet the increasing demands of large-scale workgroups that require expansion of a Gigabit Ethernet network.

Specifications

Network
Jumbo frames support	Yes
Store-and-forward	Yes
Jumbo frames	9000
Converter input interface	10Base-T, 100Base-TX, 1000Base-T
Networking standards	IEEE 802.1Q, IEEE 802.3, IEEE 802.3ab, IEEE 802.3u, IEEE 802.3x
Ethernet LAN data rates	10,100,1000 Mbit/s
Ethernet interface type	Fast Ethernet, Gigabit Ethernet
Duplex system	Full
Converter output interface	100Base-LX
Auto MDI/MDI-X	Yes
Maximum data transfer rate	1000 Mbit/s
Fiber optic connector	SC
Performance
Wavelength-division multiplexing (WDM)	No
Wavelength	1310 nm
Maximum transfer distance	10000 m
Fiber mode structure	Single-mode
Mean time between failures (MTBF)	50000 h
Features
LED indicators	Activity, Link, Power
Product colour	Black
Internal	No
Ports & interfaces
Power over Ethernet (PoE) ports quantity	0
Connectivity technology	Wired
Ethernet LAN (RJ-45) ports	1
Fiber ports quantity	1
Power
Power plug type	Type N
Input voltage	100 - 240 V
Input current	0.5 A
Output voltage	5 V
Output current	2.6 A
External power adapter	Yes
Weight & dimensions
Width	105 mm
Depth	70 mm
Weight	196 g
Height	26 mm
Package depth	226 mm
Package width	120 mm
Package height	70 mm
Package weight	560 g
Operational conditions
Operating temperature (T-T)	0 - 50 °C
Storage temperature (T-T)	-10 - 70 °C
Operating relative humidity (H-H)	5 - 90%
Packaging content
Quick installation guide	Yes
AC adapter included	Yes
Technical details
Harmonized System (HS) code	85176990
Compliance certificates	RoHS
Design
Certification	CE, FCC
Logistics data
Master (outer) case width	368 mm
Master (outer) case length	582 mm
Master (outer) case height	306 mm
Products per master (outer) case	20 pc(s)
