StarTech.com Multiport Adapter PD USB-C Docking Station 140W (168B)

One cable, full desk: the StarTech.com Multiport Adapter PD turns your laptop into a workstation with external displays, 140W charging over a single USB-C connection.

Create a mobile workstation wherever you work with an HDMI display, USB-A 5Gbps, and 140W PD pass-through with USB-C 5Gbps

Turn a single USB-C port on a laptop, iPad, or tablet into display, power, and data connectivity with a compact adapter built for standardized IT deployments.

Standardize Mobile Connectivity with One Adapter

Turn one USB-C port into HDMI, USB-C, and USB-A, expanding connectivity without sacrificing ports. This adapter is ideal for mobile teams, travel kits, and field deployments, helping IT standardize accessories across mixed environments while keeping packs light.

140W Power and Data Without Losing a Port

Use the USB-C port for up to 140W Power Delivery 3.2 pass-through charging or 5Gbps data to support modern power requirements or high-speed peripherals. Keep systems charged or connected to storage without sacrificing limited USB-C ports, making this adapter ideal for hot-desk offices and conference rooms.

Support Displays and Legacy Peripherals

Drive a native 4K 60Hz HDMI display directly from the system GPU with no drivers, preserving CPU resources for demanding workloads like visualization and data analysis. A USB-A 5Gbps port ensures continued support for keyboards, mice, flash drives, and dongles, easing the transition to USB-C laptops without the need to upgrade peripherals.

Sustainable Design

The adapter features a 75% post‑consumer recycled (PCR) plastic enclosure and a 35% PCR TPE jacket, helping reduce environmental impact and support ESG requirements.

Specifications

Ports & interfaces
USB 3.2 Gen 1 (3.1 Gen 1) Type-A ports quantity	1
USB 3.2 Gen 1 (3.1 Gen 1) Type-C ports quantity	1
Host interface	USB 3.2 Gen 1 (3.1 Gen 1) Type-C
USB 2.0 ports quantity	0
HDMI ports quantity	1
HDMI version	2.0
Microphone in	No
Headphone outputs	0
Connectivity technology	Wired
USB Power Delivery (USB PD)	Yes
USB Power Delivery up to	140 W
Network
Ethernet LAN	No
Performance
Maximum digital resolution	3840 x 2160 pixels
Product colour	Black
Card reader integrated	No
Plug and Play	Yes
Data transfer rate	5 Gbit/s
HD type	4K Ultra HD
Technical details
Products per master (outer) case	30 pc(s)
Master (outer) case width	530 mm
Master (outer) case length	330 mm
Master (outer) case height	310 mm
Power
Power consumption (typical)	10 W
Output voltage	5 V
Operational conditions
Operating temperature (T-T)	0 - 45 °C
Storage temperature (T-T)	-10 - 70 °C
Operating relative humidity (H-H)	10 - 85%
Weight & dimensions
Weight	34 g
Width	40 mm
Depth	59 mm
Height	14 mm
Package weight	94 g
Package width	170 mm
Package depth	142 mm
Package height	30 mm
Packaging data
Quantity per pack	1 pc(s)
Packaging content
Quick start guide	Yes
Other features
Chipset	Parade - PS178

Downloads

• Datasheet (PDF)
