StarTech.com MSA Uncoded SFP+ Module - 10GBASE-LR - 10GbE Single Mode Fiber (SMF) Optic Transceiver - 10GE Gigabit Ethernet SFP+ - LC 10km - 1310nm - DDM Networking

The StarTech.com MSA Uncoded SFP+ Module - 10GBASE-LR - 10GbE Single Mode Fiber (SMF) Optic Transceiver - 10GE Gigabit Ethernet SFP+ - LC 10km - 1310nm - DDM is a dependable addition to any modern network installation.

10 Gbps | Single Mode Fiber | LC | 10 km (6.2 mi) | Lifetime Warranty

The SFP-10GBASE-LR-ST is an 10G MSA compliant fiber SFP+ transceiver that’s designed, programmed and tested to work with 10GBASE-LR compatible MSA switches and routers. The SFP+ transceiver module supports a maximum distance of up to 10 km (6.2 mi) and delivers dependable 10 GbE connectivity over fiber cabling.

Technical Specifications:

• Wavelength: 1310nm
• Maximum Data Transfer Rate: 10 Gbps
• Type: Single Mode Fiber
• Connection Type: LC Connector
• Maximum Transfer Distance: 10 km (6.2 mi)
• MTBF: 646,156,559 hours
• Power Consumption:
• Digital Diagnostics Monitoring (DDM): Yes

This SFP+ fiber module is hot-swappable, making upgrades and replacements seamless by minimizing network disruptions.

StarTech.com SFPs

All StarTech.com SFP & SFP+ transceiver modules are backed by a lifetime warranty and free lifetime multilingual technical support. StarTech.com offers a wide variety of SFP+ modules and direct-attach SFP+ cables, providing the convenience and reliability you need to ensure dependable network performance.

Specifications

Performance
SFP transceiver type	Fiber optic
Digital Diagnostics Monitoring (DDM)	Yes
Fiber optic connector	LC
Maximum transfer distance	10000 m
Wavelength	1310 nm
Maximum data transfer rate	10000 Mbit/s
Interface type	SFP+
Single-mode fiber (SMF) supported	Yes
Multi-mode fiber (MMF) supported	No
SFP transceiver standard	LR
Fiber ethernet cabling technology	10GBASE
Product colour	Silver
Hot-swap	Yes
Mean time between failures (MTBF)	646156559 h
Harmonized System (HS) code	85369010
Power
Power consumption (typical)	1.3 W
Weight & dimensions
Width	58.4 mm
Depth	13.9 mm
Height	13.7 mm
Weight	21 g
Package depth	113 mm
Package width	90 mm
Package height	33 mm
Package weight	50 g
Packaging content
Quantity per pack	1 pc(s)
Logistics data
Master (outer) case width	90 mm
Master (outer) case length	115 mm
Master (outer) case height	33 mm
Products per master (outer) case	1 pc(s)
