StarTech.com Dual mSATA SSD to 2.5” SATA RAID Adapter Converter - TAA Hub
StarTech.com Dual mSATA SSD to 2.5” SATA RAID Adapter Converter - TAA Hub
Regular price
£15.16 GBP
Regular price
Sale price
£15.16 GBP
Taxes included.
Quantity
Couldn't load pickup availability
The StarTech.com Dual mSATA SSD to expands your ports in seconds — plug in and go.
Build a RAID array with two mSATA SSDs that can be installed into a single 2.5in SATA bayVastly increase system performance by adding a dual mSATA SSD RAID array into any 2.5" SATA HDD application with the 25SAT22MSAT mSATA to SATA adapter.
Utilize the full potential of your SATA III controller, with mSATA SSDs reducing your data transfer bottleneck with file transfer speeds up to 6 Gbps. mSATA SSDs also save you money by reducing your power consumption over regular platter drives.
You can achieve greater SSD capacity, or data redundancy with the Dual SSD controller supporting multiple RAID modes (RAID 0, 1, BIG). The SSD adapter also supports non-RAID operation (JBOD) when paired with a port-multiplying SATA controller, so both drives can be used independent of one another.
Help protect the health of your drive with an open-frame design ensuring maximum heat dissipation.
The 25SAT22MSAT is backed by a StarTech.com 2-year warranty, and lifetime technical support.
Specifications
| Ports & interfaces | |
|---|---|
| Internal | Yes |
| Port multiplier | Yes |
| Output interface | mSATA |
| SATA revision | 3.0 |
| Host interface | SATA |
| Technical details | |
| Plug and Play | Yes |
| Chipset | JMicron JMS562 |
| RAID levels | 0, 1, BIG, JBOD |
| Data transfer rate (max) | 6 Gbit/s |
| Compliance certificates | RoHS |
| Performance | |
| Hot-swap | No |
| Product colour | Black, Green |
| Harmonized System (HS) code | 84733020 |
| Certificates | |
| Certification | CE, FCC |
| Design | |
| Mean time between failures (MTBF) | 5101299 h |
| Operational conditions | |
| Operating temperature (T-T) | -40 - 85 °C |
| System requirements | |
| Windows operating systems supported | Yes |
| Mac operating systems supported | Yes |
| Linux operating systems supported | Yes |
| Weight & dimensions | |
| Width | 70 mm |
| Depth | 97 mm |
| Height | 7 mm |
| Weight | 39 g |
| Package width | 143 mm |
| Package depth | 175 mm |
| Package height | 34 mm |
| Package weight | 107 g |
| Packaging data | |
| Mounting brackets included | Yes |
| Quick installation guide | Yes |
| Logistics data | |
| Products per master (outer) case | 60 pc(s) |
| Master (outer) case width | 382 mm |
| Master (outer) case length | 498 mm |
| Master (outer) case height | 322 mm |
