StarTech.com DisplayPort to HDMI Adapter - 4K 30Hz Active DisplayPort to HDMI Video Cable

Make the connection with the StarTech.com DisplayPort to HDMI Adapter — length and connector details are in the spec table.

Connect an HDMI monitor to a DisplayPort video source

The DP2HD4KS DisplayPort to HDMI adapter enables you to connect a DisplayPort-equipped desktop or laptop computer, such as the HP EliteBook 8570p / 8470p, to an HDMI display. This adapter is compatible with DisplayPort 1.2 & HDMI 4K @ 30 Hz and as a result can support video resolutions up to Ultra HD (4K) as well as the accompanying digital audio up to 7.1 channel surround sound.

With support for resolutions up to Ultra HD (4K) the DP to HDMI adapter ensures you can convert DisplayPort to HDMI while maintaining an astonishing picture quality four times the resolution of high-definition 1080p. The adapter is also backward compatible with previous DisplayPort revisions 1.0/1.1 with support for resolutions up to 1080p.

For a hassle-free setup the DisplayPort to HDMI adapter allows for plug-and-play installation without any additional software or drivers. Plus, with a small footprint and lightweight design, the adapter maximizes portability.

To ensure compatibility with any DisplayPort output the DP adapter offers an active conversion. Active video conversion is required to maintain 4K resolutions when converting DisplayPort to HDMI. An active DP adapter is also ideal for outputting 1080p video resolutions by ensuring compatibility with graphics cards that are not capable of outputting multi-mode DP++ signals (e.g. ATI Eyefinity).

The DP2HD4KS is backed by a 3-year StarTech.com warranty, and lifetime technical support.

Specifications

Features
HDMI version	1.4
DisplayPort version	1.2
Product colour	Black
Cable length	0.15 m
Connector 1	DisplayPort
Connector 2	HDMI Type A (Standard)
Connector 1 gender	Male
Connector 2 gender	Female
Maximum resolution	4096 x 2048 pixels
Supported graphics resolutions	1280 x 720 (HD 720), 1920 x 1080 (HD 1080), 1920 x 1200 (WUXGA)
HDCP	Yes
Connector 1 form factor	Straight
Connector 2 form factor	Straight
Maximum refresh rate	30 Hz
HDCP version	1.4
DisplayPort Content Protection (DPCP)	Yes
Supported audio channels	7.1
Operational conditions
Operating temperature (T-T)	0 - 45 °C
Storage temperature (T-T)	-10 - 70 °C
Operating relative humidity (H-H)	10 - 85%
Certificates
Compliance certificates	CE, RoHS
Other features
Width	21 mm
Height	11 mm
Depth	64 mm
Weight & dimensions
Weight	22 g
Package width	122 mm
Package depth	133 mm
Package height	16 mm
Package weight	27 g
Packaging data
Quantity per pack	1 pc(s)
Technical details
Harmonized System (HS) code	84733080
Logistics data
Master (outer) case width	517 mm
Master (outer) case length	337 mm
Master (outer) case height	223 mm
Products per master (outer) case	320 pc(s)

Downloads

• Datasheet (PDF)
