StarTech.com Conference Room Docking Station - Universal Laptop Dock - 4K HDMI, 60W Webcam

Look sharp on every call — the StarTech.com Conference Room Docking Station upgrades your video with better optics than any built-in laptop camera.

Conference Room Docking Station | 4K HDMI® | USB-C™ and USB-A | USB-C Power Delivery

Add docking and video conferencing capabilities to a boardroom, classroom or huddle space. This conference table connectivity box bundle lets you:

• Access your room's display and collaboration peripherals with a single connection
• Charge mobile devices using the USB-A charge port
• Power a supported USB-C laptop with USB Power Delivery

Dock Your Laptop

During meetings, you may need to set up video conference calls using applications such as Microsoft Teams, Zoom or Google Hangouts. Unlike other boardroom conferencing solutions that are limited to only one or two collaboration applications, this module lets you use your own laptop, so you are not restricted to a specific platform.

Connect a USB-C or USB-A laptop to the module and access your room's peripherals, webcams, speakers, mics, network and HDMI display. This conference table AV box and docking station module lets you easily connect your laptop with each video conferencing device in your boardroom. You can collaborate with others in the room and around the globe.

For users that are unable to dock or for quick access to the display, the front-facing HDMI port lets you connect a laptop directly to the display.

Easy, Stylish and Clean Installation

Design a practical and stylish solution that impresses your visitors and facilitates their needs. The in-table connectivity box is easy to install in a conference room table, desk or lectern, and features a black aluminum finish that complements your table and your peripherals.

KITBZDOCK is backed by a StarTech.com 2-year warranty and free lifetime technical support.

The StarTech.com Advantage

Specifications

Video
Maximum resolution	3840 x 2160 pixels
Maximum refresh rate	30 Hz
Network
Ethernet LAN	Yes
Ethernet interface type	Fast Ethernet, Gigabit Ethernet
Networking standards	IEEE 802.3, IEEE 802.3ab, IEEE 802.3u
Full duplex	Yes
Data transfer rate (max)	5 Gbit/s
Auto MDI/MDI-X	Yes
Design
Product colour	Black
Housing material	Aluminium
LED indicators	Power
Features
Chipset	DisplayLink - DL-6950, Genesys Logic - GL850G, Texas Instruments - TPS65982, Parade Technologies - PS176, VIA Labs - VL813, Realtek - RTL8153
Operating systems supported	Windows 7, 8, 8.1, 10 macOS 10.9 - 10.12, 10.14 - 10.15, 11.0, 12.0, 13.0 Ventura Chrome OS v55+
Ports & interfaces
Audio input	1
Audio output	1
Ethernet LAN (RJ-45) ports	1
DC-in jack	Yes
USB 3.2 Gen 1 (3.1 Gen 1) Type-B ports quantity	1
HDMI input ports quantity	2
HDMI output ports quantity	1
USB 3.2 Gen 1 (3.1 Gen 1) Type-A ports quantity	4
USB 3.2 Gen 1 (3.1 Gen 1) Type-C ports quantity	1
UASP support	Yes
Power
Input current	2 A
AC adapter input voltage	100 - 240 V
AC adapter output voltage	20 V
AC adapter output current	6 A
Power plug type	Type N
Operational conditions
Operating temperature (T-T)	0 - 40 °C
Storage temperature (T-T)	-20 - 65 °C
Operating relative humidity (H-H)	20 - 80%
Technical details
Compliance certificates	CE, RoHS
Weight & dimensions
Width	145 mm
Package width	190 mm
Package depth	192 mm
Depth	100 mm
Package height	134 mm
Height	115 mm
Weight	1.1 kg
Package weight	3 kg
Logistics data
Master (outer) case width	190 mm
Master (outer) case length	192 mm
Master (outer) case height	134 mm
Products per master (outer) case	1 pc(s)
