StarTech.com Cisco SFP-GE-T Compatible SFP Module - 1000BASE-T - SFP to RJ45 Cat6/Cat5e - 10/100/1000 Mbps - RJ-45 100m - Cisco IE3400, IE3300, IE3200 Networking

The StarTech.com Cisco SFP-GE-T Compatible SFP Module - 1000BASE-T - SFP to RJ45 Cat6/Cat5e - 10/100/1000 Mbps - RJ-45 100m - Cisco IE3400, IE3300, IE3200 is a dependable addition to any modern network installation.

10/100/1000 Mbps | Copper | RJ45 | 100 m (328 ft) | Lifetime Warranty

The SFPC1110 is a Cisco SFP-GE-T compatible copper transceiver module that has been designed, programmed and tested to work with Cisco® brand switches and routers. It delivers dependable 1GbE (1000 Mbps) connectivity over copper cable, for 1000BASE-T compliant networks, with a maximum distance of up to 100 m (328 ft).

Technical Specifications:

• Maximum Data Transfer Rate: 1.25 Gbps
• Type: Copper
• Connection Type: RJ45 Connector
• Maximum Transfer Distance: 100 m (328 ft)
• MTBF: 4,655,371 hours
• Power Consumption: Less than 1.3 Watts
• Digital Diagnostics Monitoring (DDM): No

This SFP copper module is hot-swappable, making upgrades and replacements seamless by minimizing network disruptions.

StarTech.com SFPs

All StarTech.com SFP & SFP+ transceiver modules are backed by a lifetime warranty and free lifetime multilingual technical support. StarTech.com offers a wide variety of SFP modules and direct-attach SFP cables, providing the convenience and reliability you need to ensure dependable network performance.

Specifications

Performance
SFP transceiver type	Copper
Digital Diagnostics Monitoring (DDM)	Yes
Auto-negotiation	Yes
Fiber optic connector	SFP
Networking standards	IEEE 802.3ab
Auto MDI/MDI-X	Yes
Ethernet LAN (RJ-45) ports	1
Maximum transfer distance	100 m
Cabling technology	1000BASE-T
Maximum data transfer rate	1250 Mbit/s
Interface type	SFP
Product colour	Silver
Hot-swap	Yes
Mean time between failures (MTBF)	4655371 h
Harmonized System (HS) code	85369010
Features
Certification	CE, FCC, UL, REACH
Power
Power consumption (typical)	1.3 W
Certificates
Compliance certificates	RoHS
Operational conditions
Operating temperature (T-T)	0 - 70 °C
Storage temperature (T-T)	-40 - 85 °C
Operating relative humidity (H-H)	30 - 70%
Weight & dimensions
Width	13 mm
Depth	70 mm
Height	13 mm
Weight	46 g
Package depth	113 mm
Package width	91 mm
Package height	33 mm
Package weight	55 g
Packaging content
Quantity per pack	1 pc(s)
Logistics data
Master (outer) case width	206 mm
Master (outer) case length	298 mm
Master (outer) case height	248 mm
Products per master (outer) case	36 pc(s)
