StarTech.com Cisco SFP-10GB-TC Compatible SFP+ Module - 10GBASE-T - SFP to RJ45 Cat6/Cat5e - 10GE Gigabit Ethernet SFP+ - RJ-45 30m - Cisco Firepower, ASR1000, ASR9000 Networking

The StarTech.com Cisco SFP-10GB-TC Compatible SFP+ Module - 10GBASE-T - SFP to RJ45 Cat6/Cat5e - 10GE Gigabit Ethernet SFP+ - RJ-45 30m - Cisco Firepower, ASR1000, ASR9000 is a dependable addition to any modern network installation.

10Gbps | Copper | RJ45 | 30 m (100 ft) | Lifetime Warranty

The SFP10GBTCST is a Cisco compatible copper transceiver module that has been designed, programmed and tested to work with Cisco® brand switches and routers. It delivers dependable 10 GbE connectivity over copper cable, for 10GBASE-T compliant networks, with a maximum distance of up to 30 m (98.4 ft).

Technical Specifications:

• Maximum Data Transfer Rate: 10 Gbps
• Type: Copper
• Connection Type: RJ45 Connector
• Maximum Transfer Distance: 30 m (98.4 ft)
• MTBF: 4,598,430 hours
• Digital Diagnostics Monitoring (DDM): No

This SFP+ copper module is hot-swappable, making upgrades and replacements seamless by minimizing network disruptions.

StarTech.com SFPs

All StarTech.com SFP & SFP+ transceiver modules are backed by a lifetime warranty and free lifetime multilingual technical support. StarTech.com offers a wide variety of SFP modules and direct-attach SFP cables, providing the convenience and reliability you need to ensure dependable network performance.

Specifications

Performance
SFP transceiver type	Copper
Digital Diagnostics Monitoring (DDM)	No
Networking standards	IEEE 802.3an
Auto MDI/MDI-X	Yes
Maximum transfer distance	30 m
Duplex system	Full, Half
Maximum data transfer rate	10000 Mbit/s
Interface type	SFP+
Country of origin	Taiwan
Product colour	Silver
Housing material	Zinc steel
Hot-swap	Yes
Mean time between failures (MTBF)	4598430 h
Brand compatibility	Cisco
Harmonized System (HS) code	85369010
Features
Certification	CE, FCC
Power
Power consumption (typical)	2.3 W
Certificates
Compliance certificates	RoHS
Operational conditions
Operating temperature (T-T)	0 - 70 °C
Storage temperature (T-T)	-40 - 90 °C
Operating relative humidity (H-H)	0 - 95%
Weight & dimensions
Width	13.4 mm
Depth	69.8 mm
Height	14 mm
Weight	58 g
Package depth	75 mm
Package width	120 mm
Package height	34 mm
Packaging content
Quantity per pack	1 pc(s)
Logistics data
Master (outer) case width	643 mm
Master (outer) case length	348 mm
Master (outer) case height	291 mm
Products per master (outer) case	150 pc(s)

Downloads

• Datasheet (PDF)
• Product manual / brochure (PDF)
