StarTech.com Cisco GLC-TE Compatible Module - 1000BASE-T Copper Industrial Gigabit Ethernet Transceiver - SFP to RJ45 Cat6/Cat5e 100m Extended Temp - Cisco Firepower, IE 2000, C9500, C2960 Networking

The StarTech.com Cisco GLC-TE Compatible Module - 1000BASE-T Copper Industrial Gigabit Ethernet Transceiver - SFP to RJ45 Cat6/Cat5e 100m Extended Temp - Cisco Firepower, IE 2000, C9500, C2960 is a dependable addition to any modern network installation.

1000 Mbps (1 Gbps) | Copper | RJ45 | 100 m (328 ft) | Lifetime Warranty

The GLCTEST is a Cisco GLC-TE compatible copper transceiver module that has been designed, programmed and tested to work with Cisco® brand switches and routers for extended temperatures. It delivers dependable 1 GbE connectivity over copper cable, for 1000BASE-T compliant networks, with a maximum distance of up to 100 m (328 ft).

Technical Specifications:

• Maximum Data Transfer Rate: 1000 Mbps
• Type: Copper
• Connection Type: RJ45 Connector
• Maximum Transfer Distance: 100 m (328 ft)
• MTBF: 4,655,371 hours
• Power Consumption: Less than 1.3 Watts
• Digital Diagnostics Monitoring (DDM): No

This SFP copper module is hot-swappable, making upgrades and replacements seamless by minimizing network disruptions.

StarTech.com SFPs

All StarTech.com SFP & SFP+ transceiver modules are backed by a lifetime warranty and free lifetime multilingual technical support. StarTech.com offers a wide variety of SFP modules and direct-attach SFP cables, providing the convenience and reliability you need to ensure dependable network performance.

Specifications

Performance
SFP transceiver type	Copper
Digital Diagnostics Monitoring (DDM)	No
Networking standards	IEEE 802.3
Maximum transfer distance	100 m
Maximum data transfer rate	1250 Mbit/s
Interface type	SFP
Copper ethernet cabling technology	1000BASE
Country of origin	China
Product colour	Silver
Hot-swap	Yes
Compatible products	C1000, C2960S, C3560, C3750, C9400, C9500, N3500, N2000, N5000, N7000, N7700, UCSB, IE2000, Firepower, ISR4000
Mean time between failures (MTBF)	4655371 h
Brand compatibility	Cisco
Harmonized System (HS) code	85369010
Features
Certification	CE, FCC, REACH
Power
Power consumption (typical)	1.3 W
Certificates
Compliance certificates	RoHS
Operational conditions
Operating temperature (T-T)	-40 - 85 °C
Storage temperature (T-T)	-40 - 85 °C
Operating relative humidity (H-H)	30 - 75%
Weight & dimensions
Width	14 mm
Depth	65 mm
Height	12 mm
Weight	72 g
Package depth	91 mm
Package width	113 mm
Package height	34 mm
Package weight	50 g
Packaging content
Quantity per pack	1 pc(s)
Logistics data
Master (outer) case width	430 mm
Master (outer) case length	345 mm
Master (outer) case height	359 mm
Products per master (outer) case	120 pc(s)

Downloads

• Datasheet (PDF)
• Product manual / brochure (PDF)
