StarTech.com 6ft (2m) USB C to HDMI Cable - 4K 30Hz USB Type-C to HDMI Video Display

Make the connection with the StarTech.com 6ft (2m) — length and connector details are in the spec table.

Eliminate clutter by connecting your USB Type-C computer directly to an HDMI display without additional adapters

This USB-C™ to HDMI® adapter cable offers a convenient solution for directly connecting your DisplayPort over USB Type-C™ device to your HDMI monitor, television or projector. The adapter supports a connection distance of up to 2 m (6.6 ft.) and works with USB-C devices that support DP alt mode, such as the MacBook, ChromeBook Pixel™ and Dell™ XPS™ models 15 and 13. It's also compatible with Thunderbolt™ 3 ports.

Clutter-free installation

At 2 m (6.6 ft.) in length, this adapter cable delivers a direct connection that eliminates excess adapters and cabling, ensuring a tidy, professional installation. For shorter installations, we also offer a 1 m (3.3 ft.) USB-C to HDMI cable, enabling you to choose the right cable length for your custom installation needs.

Hassle-free connection with USB Type-C

The adapter cable is easy to connect, through the versatility and convenience of the USB Type-C port on your device. USB-C is a reversible connector, so it doesn't matter which way you plug it in, the adapter will always connect. This saves you the frustration of trying to insert it correctly when you're docking your computer to your workstation or office hot desk.

Astonishing picture quality

At four times the resolution of high-definition 1080p, you'll be amazed at the picture quality of a 4K monitor or television. This adapter cable lets you harness the video capabilities that are built into your USB Type-C connection to deliver the astonishing quality of Ultra HD to your 4K display.

The adapter is backward compatible with 1080p displays, ensuring the adapter will also work for HD applications at your home or office.

Note:

Your USB-C equipped device must support video (DP alt mode) to work with this adapter.

Specifications

Features
Chipset	Parade - PS171, NXP - PTN5100
HDMI version	1.4
Product colour	Black
Cable length	2 m
Connector 1	USB Type-C
Connector 2	HDMI
Connector 1 gender	Male
Connector 2 gender	Male
Maximum resolution	3840 x 2160 pixels
Supported graphics resolutions	1024 x 768 (XGA), 1280 x 720 (HD 720), 1920 x 1080 (HD 1080), 1920 x 1200 (WUXGA), 2560 x 1440, 2560 x 1600 (WQXGA), 3840 x 2160
Supported video modes	720p, 1080p, 2160p
Plug and Play	Yes
Certification	CE, FCC, REACH
Connector 1 form factor	Straight
Connector 2 form factor	Straight
Maximum refresh rate	30 Hz
Supported audio channels	7.1
Operational conditions
Operating temperature (T-T)	0 - 45 °C
Storage temperature (T-T)	-10 - 70 °C
Operating relative humidity (H-H)	5 - 90%
Certificates
Compliance certificates	RoHS
Other features
Depth	2000 mm
Weight & dimensions
Weight	118 g
Package width	122 mm
Package depth	166 mm
Package height	32 mm
Package weight	127 g
Packaging data
Quantity per pack	1 pc(s)
Technical details
Harmonized System (HS) code	84733080
Logistics data
Master (outer) case width	516 mm
Master (outer) case length	347 mm
Master (outer) case height	217 mm
Products per master (outer) case	60 pc(s)

Downloads

• Datasheet (PDF)
• Product manual / brochure (PDF)
