StarTech.com 4 Port USB C Hub (10Gbps) to 3x USB-A & 1x USB-C - 100W Power Delivery

The StarTech.com 4 Port expands your ports in seconds — plug in and go.

USB Type-C™ Gen 2 | PD 3.0 | 25 cm Cable | Bus-Powered | Mac & Windows®

Expand the connectivity of your USB-C laptop with this new generation USB-C Gen 2 hub offering 10Gbps supporting greater bandwidth to connected devices and faster data transfer speeds. This bus-powered 4-Port USB-C hub plugs into your laptop’s USB Type-C™ or Thunderbolt™ 3 port, adding one USB-C port and three USB-A ports, while allowing charging of your laptop.

Power Delivery 3.0 for Laptop Charging

The USB-C hub can support Power Delivery (3.0) pass through, when using a USB-C power adapter, to charge your laptop, with 15W reserved to power the hub itself.

Convenient Portability and Easy Setup

This compact, lightweight USB-Type-C hub is a convenient and portable addition to your laptop accessories. The USB-C cable is built-in, and hub is bus-powered, so it draws its power directly from your computer’s USB-C port, with no external power required. That means fewer cables to carry with you when you travel. The hub can draw up to 15 Watts of power from the connected host and operating multiple bus powered devices at one time with the total available power dependent on the connected host.

The extended length attached cable of 9.8” (25 cm) provides more flexibility for longer reach connection requirements and plug-and-play installation.

Connect More USB Devices

With ports for both USB-C and USB-A peripherals, this hub is backwards compatible supporting both legacy and new USB devices. You can connect flash drives, video capture devices and external hard drives, with fast data transfer speeds of up to 10Gbps. This 4-port USB Type-C hub enhances your productivity, giving you the connections, you need while you work.

HB31C3A1CPD3 is backed by a StarTech.com 2-year warranty and free lifetime technical support.

Specifications

Ports & interfaces
Host interface	USB 3.2 Gen 2 (3.1 Gen 2) Type-C
USB 3.2 Gen 2 (3.1 Gen 2) Type-A ports quantity	3
USB 3.2 Gen 2 (3.1 Gen 2) Type-C ports quantity	1
Hub interfaces	USB 3.2 Gen 2 (3.1 Gen 2) Type-A, USB 3.2 Gen 2 (3.1 Gen 2) Type-C
DC-in jack	No
Card reader integrated	No
Ports quantity	4
Cable length	0.25 m
Features
Plug and Play	Yes
Product colour	Black, Grey
Certification	CE, FCC, REACH, RoHS
Data transfer rate	10000 Mbit/s
USB Power Delivery (USB PD)	Yes
Housing material	Aluminium, Plastic
USB Power Delivery up to	85 W
Network
UASP support	Yes
Power
Power consumption (typical)	13.5 W
Power supply	100 W
Power supply type	USB
Performance
Harmonized System (HS) code	84719000
Weight & dimensions
Weight	68 g
Width	45 mm
Depth	105 mm
Height	15 mm
Package width	210 mm
Package depth	147 mm
Package height	42 mm
Package weight	177 g
Packaging data
Quantity per pack	1 pc(s)
Operational conditions
Operating temperature (T-T)	0 - 50 °C
Storage temperature (T-T)	-20 - 70 °C
Operating relative humidity (H-H)	0 - 95%
Logistics data
Master (outer) case width	457 mm
Master (outer) case length	319 mm
Master (outer) case height	448 mm
Products per master (outer) case	40 pc(s)
Other features
Chipset	RTS5423

Downloads

• Datasheet (PDF)
• Product manual / brochure (PDF)
