StarTech.com 2-Post 15U Heavy-Duty Wall Mount Network Rack, 19" Open Frame Server
StarTech.com 2-Post 15U Heavy-Duty Wall Mount Network Rack, 19" Open Frame Server
Regular price
£139.72 GBP
Regular price
Sale price
£139.72 GBP
Taxes included.
Quantity
Couldn't load pickup availability
Build a tidy install with the StarTech.com 2-Post 15U Heavy-Duty Wall — dimensions and mounting details are in the spec table.
Mount your network and telecommunications equipment with the convenience of adjustable depthThis open frame wallmount server rack provides 15U of storage, helping you to save space and stay organized. The equipment rack features an adjustable depth and can hold a total of up to 198 lb (90 kg).
Accommodate Larger Devices
The open frame rack adjusts from 12 to 20 inches (30.4 to 50.8 cm) to accommodate larger data, network, and telecommunication devices. The above-average depth also gives you the option to mount shelves and other accessories.
Free up Floor Space
When space is limited you can wall-mount the open-frame rack in a server room, office, or above a doorway, to expand your workspace and ensure your equipment is easy to access.
Keep Equipment Cool and Accessible
The rack's open frame design promotes passive cooling; ensures easy access to your rack-mounted equipment and makes it simple to configure mounted devices, which saves you time.
Easy, Hassle-Free Installation
With an adjustable depth as low as 12 inches (30.4 cm), this network rack is perfect for smaller spaces. It's easy to assemble and features wall-mounting holes that are spaced 12 and 16 in. apart, making it suitable for mounting on almost any wall, based on North American wall-frame stud-spacing standards.
Specifications
| Weight & dimensions | |
|---|---|
| Package depth | 537 mm |
| Package width | 817 mm |
| Package height | 147 mm |
| Package weight | 17.8 kg |
| Mounting depth (max) | 50.6 cm |
| Width | 504 mm |
| Depth | 510 mm |
| Height | 773 mm |
| Weight | 15.2 kg |
| Maximum weight capacity | 90 kg |
| Packaging content | |
| Manual | Yes |
| Nuts included | Yes |
| Number of nuts | 60 |
| Screws included | Yes |
| Number of screws | 76 |
| Number of bolts | 24 |
| Number of washers included | 84 |
| Features | |
| Number of fans | 0 fan(s) |
| Frame type | Open |
| Product design | 2-post |
| Rack capacity | 15U |
| Adjustable mounting rails | No |
| Cable management | No |
| Mounting hole shape | Square |
| Type | Wall mounted rack |
| Material | Steel |
| Product colour | Black |
| Certification | CE, REACH |
| Technical details | |
| Compliance industry standards | EIA/ECA-310-E |
| Harmonized System (HS) code | 85381000 |
| Compliance certificates | RoHS |
| Logistics data | |
| Master (outer) case width | 530 mm |
| Master (outer) case length | 800 mm |
| Master (outer) case height | 130 mm |
| Products per master (outer) case | 1 pc(s) |
