StarTech.com 1U 19 inch Server Rack Rails - 24-36 inch Adjustable Depth - Universal
StarTech.com 1U 19 inch Server Rack Rails - 24-36 inch Adjustable Depth - Universal
Regular price
£50.01 GBP
Regular price
Sale price
£50.01 GBP
Taxes included.
Quantity
Couldn't load pickup availability
Build a tidy install with the StarTech.com 1U 19 inch Server — dimensions and mounting details are in the spec table.
Universal | EIA/ECA-310 Compliant | Supports up to 200lbsThese 1U server rack rails let you mount devices, such as servers or networking equipment, that did not come with rack rails into your 19” 4 post rack. The adjustable server rack rails are also a great solution for mounting OEM equipment such as Dell™, IBM®, HP® or Apple servers.
Universal design mounts to almost any 19" server rack
Adhering to the EIA/ECA-310 standard for 19 inch server rack equipment and accessories, these mounting rails are compatible with most 19 inch server racks. The depth is adjustable for a variety of rack sizes and configurations up to a maximum depth of 36 inches.
Maximum durability
To ensure your equipment is secure, these universal rack mount rails feature cold-rolled steel construction. The durable design can support a weight load of up to 200 lbs (90 kg).
The Choice of IT Pros Since 1985
StarTech.com conducts thorough compatibility and performance testing on all our products to ensure we are meeting or exceeding industry standards and providing high-quality products to IT Professionals. Our local StarTech.com Technical Advisors have broad product expertise and work directly with our StarTech.com Engineers to provide support for our customers both pre and post-sales.
The UNIRAILS1UB is backed by a lifetime StarTech.com warranty with free technical support.
Specifications
| Features | |
|---|---|
| Type | Rack rail |
| Maximum weight capacity | 90.7 kg |
| Product colour | Black |
| Compliance industry standards | EIA-310-D |
| Harmonized System (HS) code | 85389099 |
| Weight & dimensions | |
| Package width | 645 mm |
| Package height | 100 mm |
| Package depth | 226 mm |
| Package weight | 4 kg |
| Mounting depth (min) | 61 cm |
| Mounting depth (max) | 91.4 cm |
| Width | 80 mm |
| Weight | 3.5 kg |
| Height | 45 mm |
| Depth | 628 mm |
| Packaging data | |
| Quantity per pack | 2 pc(s) |
| Packaging content | |
| Screws included | Yes |
| Nuts included | Yes |
| Number of screws | 8 |
| Number of nuts | 8 |
| Quick installation guide | Yes |
| Washers included | Yes |
| Number of washers included | 8 |
| Technical details | |
| Compliance certificates | CE, RoHS |
| Logistics data | |
| Master (outer) case width | 466 mm |
| Master (outer) case length | 665 mm |
| Master (outer) case height | 514 mm |
| Products per master (outer) case | 10 pc(s) |
