Netgear GS316EPP Switch PoE

The Netgear GS316EPP keeps your wired network organised with PoE power for APs and cameras.

The NETGEAR 16-Port High-Power PoE+ Gigabit Ethernet Plus Switch delivers essential business networking features and powers PoE+ devices like VoIP phones, IP cameras, and more.

Gigabit Ethernet
16 ports provide up to 1000 Mbps of dedicated, non-blocking bandwidth each

PoE+ Support
15 PoE+ ports provide a total of 231W of power so you can power and connect your devices with a single wire.

Advanced PoE Controls
Manage PoE prioritization, PoE power limit per port, PoE scheduling and more for simple control over all PoE-powered devices

Non-Blocking Switching
10Gbps (10/100/1000 Mbps) line rate fabric ensures congestion-free connectivity to your devices.

Fanless Design
Silent operation makes this switch perfect for noise-sensitive environments

Versatile Mounting Options
Install your switch on your desktop, or mount it to your wall or rack with the hardware provided in the box

Specifications

Management features
Switch type	Managed
Web-based management	Yes
Quality of Service (QoS) support	Yes
Multicast support	Yes
Ports & interfaces
SFP module slots quantity	1
Basic switching RJ-45 Ethernet ports quantity	16
Basic switching RJ-45 Ethernet ports type	Gigabit Ethernet (10/100/1000)
Gigabit Ethernet (copper) ports quantity	16
Network
Networking standards	IEEE 802.3, IEEE 802.3ab, IEEE 802.3af, IEEE 802.3at, IEEE 802.3u, IEEE 802.3x
Full duplex	Yes
VLAN support	Yes
Link aggregation	Yes
Flow control support	Yes
Broadcast storm control	Yes
Data transmission
Jumbo frames	10000
MAC address table	4000 entries
Switching capacity	28 Gbit/s
Jumbo frames support	Yes
Security
Access Control List (ACL)	Yes
DHCP features	DHCP client
Design
Product colour	Black
Stackable	No
LED indicators	Yes
Power
Power supply included	Yes
Power source	DC
Power over Ethernet (PoE)
Total Power over Ethernet (PoE) budget	231 W
Power over Ethernet (PoE) ports quantity	15
Power over Ethernet (PoE)	Yes
Operational conditions
Storage temperature (T-T)	-20 - 70 °C
Storage relative humidity (H-H)	0 - 95%
Operating temperature (T-T)	0 - 40 °C
Operating relative humidity (H-H)	0 - 90%
Operating altitude	0 - 3000 m
Non-operating altitude	0 - 3000 m
Weight & dimensions
Width	286 mm
Depth	102 mm
Height	27 mm
Weight	883 g
Performance
Harmonized System (HS) code	85176990
