Neomounts FPMA-D700D3 Monitor arm 10-27"

Position your screen exactly where you need it with the Neomounts FPMA-D700D3 Monitor arm 10-27" — VESA fit and load ratings are below.

The Neomounts desk mount, model FPMA-D700D3 is a tilt- and rotatable desk mount for 3 flat screens up to 27". This mount is a great choice for space saving placement on desks using a desk clamp.

Neomounts versatile tilt (90°), rotate (360°) and swivel (103°) technology allows the mount to change to any viewing angle to fully benefit from the capabilities of the flat screen. The mount is manually height adjustable from 32 to 42 centimetres. Depth 7 centimetres. An innovative cable management conceals and routes cables from mount to flat screen. Hide your cables to keep the workplace nice and tidy.

Neomounts FPMA-D700D3 has one pivot point and is suitable for screens up to 27" (69 cm). The weight capacity of this product is 8 kg each screen. The desk mount is suitable for screens that meet VESA hole pattern 75x75 or 100x100mm. Different hole patterns can be covered using Neomounts VESA adapter plates.

By using an ergonomic mount neck- and back complaints can be avoided. Ideal for use in offices and on counters or in a reception area.

All installation material is included with the product.

Specifications

Mounting
Maximum weight capacity (per display)	8 kg
Desk thickness (max)	9 cm
Minimum screen size	25.4 cm (10")
Panel mounting interface	100 x 100,75 x 75 mm
Number of displays supported	3
Mounting type	Desk
Minimum VESA mount	75 x 75 mm
Maximum VESA mount	100 x 100 mm
Mounting	Clamp
Distance to the wall (min)	0 mm
Distance to the wall (max)	7 cm
Maximum weight capacity	8 kg
Maximum screen size	68.6 cm (27")
Ergonomics
Depth adjustment range	0 - 70 mm
Height adjustment	Yes
Height adjustment range	320 - 420 mm
Swivel angle range	0 - 103°
Swivel angle	103°
Tilt angle range	-90 - 90°
Angle of rotation	360°
Height adjustment type	Manual
Rotating	Yes
Swivelling	Yes
Width adjustment	122.5 cm
Design
Product colour	Black
Housing material	Steel
Technical details
Width adjustment range	0 - 1225 mm
Weight & dimensions
Width	1225 mm
Depth	70 mm
Height	420 mm
Weight	9.16 kg
Package width	750 mm
Package depth	334 mm
Package height	160 mm
Package weight	9.5 kg
Other features
Country of origin	Taiwan
Logistics data
Master (outer) case width	750 mm
Master (outer) case length	334 mm
Master (outer) case height	160 mm
Master (outer) case gross weight	10.5 kg
Products per master (outer) case	1 pc(s)
Products per pallet (EU)	39 pc(s)
Master (outer) case net weight	9.5 kg
Harmonized System (HS) code	7326909890
