Neomounts FL40-430BL11 TV pole mount 17-32" - diam. 28-60 mm

Position your screen exactly where you need it with the Neomounts FL40-430BL11 TV pole mount — VESA fit and load ratings are below.

The Neomounts FL40-430BL11 is a full motion pole mount for flat screens up to 32" with a maximum weight capacity of 8 kg. The versatile tilt (60°), swivel (180°) and rotate (360°) technology allows you to create the optimum viewing angle.

The FL40-430BL11 has a depth of 11 cm and is suitable for screens that meet VESA hole pattern 75x75 to 100x100 mm. The mount includes a nifty Quick-release VESA, that allows you to attach the TV in a wink of an eye.

Specifications

Mounting
Maximum weight capacity (per display)	8 kg
Mounting type	Pole
Minimum screen size	43.2 cm (17")
Panel mounting interface	100 x 100,75 x 75 mm
Number of displays supported	1
Minimum VESA mount	75 x 75 mm
Maximum VESA mount	100 x 100 mm
Maximum screen size	81.3 cm (32")
Maximum weight capacity	8 kg
Ergonomics
Tilt angle range	-30 - 30°
Swivel angle range	0 - 180°
Swivel angle	180°
Angle of rotation	360°
Distance to the wall (min)	11 cm
Distance to the wall (max)	11 cm
Rotating	Yes
Tilt adjustment	Yes
Swivelling	Yes
Technical details
Product colour	Black
Country of origin	China
Package net weight	800 g
Master (outer) case net weight	20.4 kg
Design
Housing material	Steel
Weight & dimensions
Width	114 mm
Depth	122 mm
Height	114 mm
Weight	680 g
Depth (max)	12.2 cm
Packaging data
Package width	119 mm
Package depth	149 mm
Package height	70 mm
Package weight	800 g
Logistics data
Master (outer) case width	375 mm
Master (outer) case length	375 mm
Master (outer) case height	315 mm
Master (outer) case gross weight	23.8 kg
Products per master (outer) case	30 pc(s)
Products per pallet (EU)	720 pc(s)
Harmonized System (HS) code	7326909890

Downloads

• Datasheet (PDF)
• Product manual / brochure (PDF)
