MULTIBRACKETS M Universal Wallmount Fixed Medium Black

Position your screen exactly where you need it with the MULTIBRACKETS M Universal Wallmount Fixed — VESA fit and load ratings are below.

The Multibrackets M Universal Wallmount Fixed is a low profile fixed wall mount for 32" & 65" flat-panel TVs up to 50 Kgs. Its flush design allows it to sit just 23mm from the wall focusing looks on your TV and not the mount. Its solid construction of steel is both strong and durable. After installation the TV can slide left and right on wall plate after mounting and thus give the end-user a possibility to perfect position the TV after installing it. The quick release straps on the mounting brackets stays hidden with Multibrackets Smart magnet system, but are when needed easily pulled down to unlock the TV from the wall plate for cable access.
The Multibrackets Universal Wallmount Fixed includes a 5 year warranty.

Specifications

Mounting
Mounting type	Wall
Minimum screen size	81.3 cm (32")
Panel mounting interface	200 x 200,300 x 200,300 x 300,400 x 200,400 x 400
Number of displays supported	1
Minimum VESA mount	200 x 200 mm
Maximum VESA mount	400 x 400 mm
Maximum screen size	165.1 cm (65")
Maximum weight capacity	50 kg
Ergonomics
Distance to the wall (max)	2.3 cm
Technical details
Product colour	Black
Design
Housing material	Steel
Weight & dimensions
Width	535 mm
Weight	1.51 kg
Packaging data
Package width	210 mm
Package depth	560 mm
Package height	65 mm
Package type	Box
Package weight	2.3 kg
Logistics data
Shipping (inner) case width	27.2 cm
Shipping (inner) case length	57.3 cm
Shipping (inner) case height	44 cm
Shipping (inner) case gross weight	19.1 kg
Products per shipping (inner) case	8 pc(s)

Downloads

• Datasheet (PDF)
