Microconnect

Microconnect MC-USB3.0-F2B2-V2 interface cards/adapter Internal USB 3.2 Gen 1 (3.1 Hub

Microconnect MC-USB3.0-F2B2-V2 interface cards/adapter Internal USB 3.2 Gen 1 (3.1 Hub

Regular price £17.27 GBP
Regular price Sale price £17.27 GBP
Sale Sold out
Taxes included.
Condition
Quantity

The Microconnect MC-USB3.0-F2B2-V2 expands your ports in seconds — plug in and go.

This production is a single chip USB 3.0 Host controller which enables a PCI Express equipped platform to interface with USB Super-Speed(5Gbps),High-Speed(480Mbps),Full-Speed(12Mbps), and Low-Speed (1.5Mbps) devices, Users can easy to connect your Mass Storage, Printer, Scanner , Hub, Camera and any other USB Devices to used. low profile bracket included.

Specifications

Ports & interfaces
Internal Yes
USB 3.2 Gen 1 (3.1 Gen 1) Type-A ports quantity 2
Output interface USB 3.2 Gen 1 (3.1 Gen 1)
Host interface PCIe
Technical details
Chipset Via VL805
Bandwidth 5 Gbit/s
Quantity per pack 1 pc(s)
Power
Output voltage 5 V
Output current 0.9 A
Operational conditions
Operating temperature (T-T) 5 - 35 °C
System requirements
Windows operating systems supported Yes
Weight & dimensions
Width 90 mm
Depth 67 mm
Weight 66 g
Package width 145 mm
Package depth 112 mm
Package height 28 mm
Package weight 76 g
