Lindy DisplayPort 1.2 to HDMI 1.4 Converter Cable

Make the connection with the Lindy DisplayPort 1.2 to HDMI — length and connector details are in the spec table.

The Lindy DisplayPort 1.2 to HDMI Converter is ideal for connecting a DisplayPort equipped source such as a PC or laptop to an HDMI monitor or TV. It supports resolutions up to 4K 3840x2160@30Hz and allows audio pass-through if supported by the video source.

The converter can also be used to add another display to extend the available desktop workspace and increase productivity. It is also ideally suited for travelling due to its compact, lightweight form factor and convenient Plug and Play installation.

This Converter requires the source or graphics card to support DP++ to provide dual-mode signals.

Specifications

Features
Converter type	Passive video converter
Chipset	PS8402A
HDMI version	1.4
DisplayPort version	1.2
Product colour	Black
Cable length	0.15 m
Connector 1	DisplayPort
Connector 2	HDMI
Connector 1 gender	Male
Connector 2 gender	Female
Jacket material	Polyvinyl chloride (PVC)
Data transfer rate	10.2 Gbit/s
Maximum resolution	3840 x 2160 pixels
Supported graphics resolutions	3840 x 2160
HDCP	Yes
Certification	CE, UKCA, FCC, RoHS, REACH
Connector 1 form factor	Straight
Connector 2 form factor	Straight
HDCP version	1.4
Bend radius (min)	6 cm
Connector housing material	Acrylonitrile butadiene styrene (ABS)
Operational conditions
Operating temperature (T-T)	0 - 80 °C
Storage temperature (T-T)	-20 - 70 °C
Operating relative humidity (H-H)	10 - 85%
Weight & dimensions
Cable diameter	5 mm
Weight	30 g
Package width	160 mm
Package depth	20 mm
Package height	160 mm
Package weight	38 g
Connector 1 dimensions (WxDxH)	20.8 x 51 x 11.5 mm
Connector 2 dimensions (WxDxH)	20.1 x 44.5 x 9 mm
Packaging data
Package type	Polybag
Quantity per pack	1 pc(s)
Technical details
Harmonized System (HS) code	84733080
