Lenovo X722 Internal Ethernet 1000 Mbit/s Network Adapter
Lenovo X722 Internal Ethernet 1000 Mbit/s Network Adapter
Regular price
£68.64 GBP
Regular price
Sale price
£68.64 GBP
Taxes included.
Quantity
Couldn't load pickup availability
Upgrade your connectivity with the Lenovo X722 Internal Ethernet — ports, speeds and interface details are in the spec table.
The Intel Ethernet Connection X722 is a network controller embedded into the Intel C624 "Lewisburg" PCH chipset of Lenovo ThinkSystem servers. The controller connects to available 10 GbE and 1 Gigabit Ethernet LAN-on-motherboard (LOM) adapter cards and onboard connectors to provide a comprehensive 1 GbE / 10 GbE networking solution for ThinkSystem customers.ThinkSystem servers support either 10 Gb Ethernet copper or optical connections, or Gigabit Ethernet connections depending on the server model.
The following figure shows the ThinkSystem 10Gb 4-port SFP+ LOM adapter which provides four SFP+ cages for optical or direct-attach copper (DAC) connectivity.
Specifications
| Ports & interfaces | |
|---|---|
| Internal | Yes |
| Ethernet LAN (RJ-45) ports | 4 |
| Interface | Ethernet |
| Host interface | PCI Express |
| Connectivity technology | Wired |
| Bandwidth | |
| Maximum data transfer rate | 1000 Mbit/s |
| Network | |
| Chipset | Intel® C624 |
| VLAN tagging | Yes |
| Jumbo frames | 9728 |
| Quality of Service (QoS) support | Yes |
| Security algorithms | SNMP |
| Networking standards | IEEE 802.1Q, IEEE 802.1Qbg, IEEE 802.1p, IEEE 802.3ad, IEEE 802.3x |
| Jumbo frames support | Yes |
| Ethernet LAN data rates | 10,100,1000 Mbit/s |
| Flow control support | Yes |
| Technical details | |
| Compatible products | SR630 SR650 SR850 SR860 SR950 |
| Product colour | Green |
| Receive Side Scaling (RSS) | Yes |
| PCI-SIG* SR-IOV Capable | Yes |
| Number of VLANs | 4096 |
| Harmonized System (HS) code | 85176990 |
| Compliance certificates | RoHS |
| Design | |
| Certification | UL recognized to UL60950-1 2nd Edition FCC Rules, Part 15, Class A Australian EMC Framework (RCM) Japan VCCI, Class A Industry Canada, ICES-003, Class A EU (CE Mark) Korea KC-RRA, Class A |
| Software | |
| Linux operating systems supported | Red Hat Enterprise Linux WS 6.0, Red Hat Enterprise Linux WS 7.0, openSUSE 11.3, openSUSE 11.4, openSUSE 12.1, openSUSE 12.2 |
| Other operating systems supported | VMware vSphere ESXi |
| System requirements | |
| Server operating systems supported | Windows Server 2012 R2, Windows Server 2012 R2 x64, Windows Server 2016 |
