iiyama ProLite TF2415MC-B2 23.8" Full HD VA Touch Monitor
iiyama ProLite TF2415MC-B2 23.8" Full HD VA Touch Monitor
Couldn't load pickup availability
The iiyama ProLite TF2415MC-B2 brings touch control to a 23.8" Full HD 1920x1080 VA monitor — ideal for POS, kiosks and interactive work.
The ProLite TF2415MC-B2 (23.8 inch) uses PCAP touch technology and is built into an eye-catching bezel with edge-to-edge glass. Thanks to a glass overlay covering the screen and a rugged bezel, it guarantees high durability and scratch-resistance, making it perfect for kiosk and high use public facing applications. Equipped with a foam seal finish it supports seamless integration into kiosks and provides IP65 rating resulting in dust and water resistance from the front. Landscape, portrait and face-up orientation ensures flexible mounting possibilities in almost any installation. For ease of integration, the TF2415MC-B2 can be equipped with optional external mounting brackets ( OMK2-1 ) making it an ideal solution for kiosk integrators, industrial environments, control rooms and interactive multimedia.
Specifications
| Display | |
|---|---|
| HDCP | Yes |
| Display brightness (typical) | 350 cd/m² |
| Screen shape | Flat |
| Display number of colours | 16.78 million colours |
| Native aspect ratio | 16:9 |
| HD type | Full HD |
| Display technology | LED |
| Viewing angle, horizontal | 178° |
| Viewing angle, vertical | 178° |
| Pixel pitch | 0.2745 x 0.2745 mm |
| Horizontal scan range | 31.4 - 82 kHz |
| Vertical scan range | 56 - 75 Hz |
| Aspect ratio | 16:9 |
| Viewable size, horizontal | 52.7 cm |
| Viewable size, vertical | 29.6 cm |
| Separate H/V sync | Yes |
| Display resolution | 1920 x 1080 pixels |
| Response time | 16 ms |
| Display diagonal | 60.5 cm (23.8") |
| Contrast ratio (typical) | 3000:1 |
| Surface hardness | 7H |
| Touchscreen type | Multi-user |
| Touchscreen | Yes |
| Number of simultaneous touchpoints | 10 |
| Panel type | VA |
| Display diagonal (metric) | 60.5 cm |
| Touch technology | Multi-touch |
| Touchscreen technology | Projected capacitive system |
| Display brightness | 315 cd/m² |
| Performance | |
| Built-in microphone | No |
| Built-in camera | No |
| AMD FreeSync | No |
| Compatible operating systems | All iiyama monitors are Plug & Play and compatible with Windows and Linux. For details regarding the supported OS for the touch models, please refer to the driver instruction file available in the downloads section. |
| NVIDIA G-SYNC | No |
| OmniTapps Multitouch compatibility | No |
| Management features | |
| On Screen Display (OSD) | Yes |
| Number of OSD languages | 7 |
| On Screen Display (OSD) languages | Traditional Chinese, German, English, Spanish, French, Italian, Japanese |
| Plug and Play | Yes |
| Design | |
| Certification | CB, CE, TÜV-Bauart, CU, cULus |
| Product colour | Black |
| Front bezel colour | Black |
| International Protection (IP) code | IP65 |
| Ports & interfaces | |
| VGA (D-Sub) ports quantity | 1 |
| HDMI ports quantity | 1 |
| DisplayPorts quantity | 1 |
| Audio output | 1 |
| HDMI | Yes |
| USB Touch port | Yes |
| Technical details | |
| Height (without stand) | 347 mm |
| Depth (without stand) | 42.5 mm |
| Width (without stand) | 575 mm |
| Placement supported | Horizontal/Vertical |
| Display viewable area (HxV) | 527.04 x 296.46 mm |
| User controls | picture (contrast, brightness, H. position, V. position, phase, clock, auto adjust), advanced (color temp., sharpness), OSD (timeout, position, H. position, V. position, touch switch), option (reset, language, source select, display mode, factory) |
| Sustainability certificates | ErP |
| Compliance certificates | CB, CE, cULus, REACH, RoHS, WEEE |
| Packaging content | AC adapter, Touch Panel Driver Disk (CD-ROM), external control pad |
| Brightness | 315 cd/m² |
| Power supply type | External |
| Active display area (W x H) | 527.04 x 296.46 mm |
| Weight (with stand) | 5.8 kg |
| Touch method | stylus, finger, glove (latex) |
| Ergonomics | |
| Wall mountable | Yes |
| VESA mounting | Yes |
| Panel mounting interface | 100 x 100 mm |
| Power | |
| Power consumption (standby) | 1.06 W |
| Power consumption (typical) | 24.4 W |
| Power consumption (off) | 0.32 W |
| Energy efficiency scale | A to G |
| AC adapter output voltage | 12 V |
| Energy efficiency class (SDR) | E |
| Energy consumption (SDR) per 1000 hours | 22 kWh |
| Operational conditions | |
| Operating temperature (T-T) | 0 - 40 °C |
| Storage temperature (T-T) | -20 - 60 °C |
| Operating relative humidity (H-H) | 20 - 80% |
| Storage relative humidity (H-H) | 10 - 90% |
| Weight & dimensions | |
| Width (with stand) | 575 mm |
| Depth (with stand) | 42.5 mm |
| Height (with stand) | 347 mm |
| Weight (without stand) | 5.8 kg |
| Width | 575 mm |
| Weight | 5.8 kg |
| Height | 347 mm |
| Depth | 42.5 mm |
| Packaging content | |
| Quick start guide | Yes |
| Cables included | AC, USB, HDMI, DisplayPort |
| AC adapter included | Yes |
| Other features | |
| Glass protection | Yes |
| Control panel | Menu, Scroll up/ Brightness, Scroll down/ Contrast, Select, Power |
| Supplied AC adapter type | AC |
| Logistics data | |
| Harmonized System (HS) code | 85285210 |
