iiyama OPC51204BC-1 Core i5-12450H 8GB 256GB SSD Mini PC
iiyama OPC51204BC-1 Core i5-12450H 8GB 256GB SSD Mini PC
Regular price
£736.27 GBP
Regular price
Sale price
£736.27 GBP
Taxes included.
Quantity
Couldn't load pickup availability
Small enough to hide behind a monitor, the iiyama OPC51204BC-1 still packs Core i5-12450H with 8GB RAM for full desktop duty.
This mini OPS PC with Intel® Core i5 inside turns your iiyama (interactive) large format display into a stand-alone solution. It comes equipped with a powerful Intel® processor with integrated Ultra HD graphics and a fast SSD drive. No hassle with cables and having to mount a PC at the back of the monitor or on a floor lift. The OPC51204BC-1 is also very quiet with a noise level below 34dB at 100% CPU load at 1 meter distance. Simply slide in the iiyama OPS slot PC and get started right away.
Specifications
| Processor | |
|---|---|
| Processor generation | 12th gen Intel® Core™ i5 |
| Processor cache type | Smart Cache |
| Processor cache | 12 MB |
| Processor model | i5-12450H |
| Processor manufacturer | Intel |
| Processor cores | 8 |
| Processor family | Intel® Core™ i5 |
| Performance cores | 4 |
| Efficient cores | 4 |
| Processor base power | 45 W |
| Maximum turbo power | 95 W |
| Efficient-core Max Turbo Frequency | 3.3 GHz |
| Performance-core Max Turbo Frequency | 4.4 GHz |
| Memory | |
| Internal memory | 8 GB |
| Maximum internal memory | 32 GB |
| Internal memory type | DDR4-SDRAM |
| Memory clock speed | 3200 MHz |
| Storage | |
| Storage media | SSD |
| Optical drive type | No |
| SSD interface | PCI Express |
| SSD capacity | 256 GB |
| Number of SSDs installed | 1 |
| Total storage capacity | 256 GB |
| SSD form factor | M.2 |
| Total SSDs capacity | 256 GB |
| Graphics | |
| Discrete graphics card | No |
| On-board graphics card family | Intel® UHD Graphics |
| On-board graphics card | Yes |
| Discrete graphics card model | Not available |
| On-board graphics card model | Intel® UHD Graphics |
| On-board GPU manufacturer | Intel |
| Network | |
| Ethernet LAN | Yes |
| Wi-Fi | Yes |
| Bluetooth | Yes |
| Bluetooth version | 5.2 |
| Wi-Fi standards | 802.11a, 802.11b, 802.11g, Wi-Fi 4 (802.11n), Wi-Fi 5 (802.11ac), Wi-Fi 6 (802.11ax) |
| Ethernet LAN data rates | 100,10,1000 Mbit/s |
| Top Wi-Fi standard | Wi-Fi 6 (802.11ax) |
| Ports & interfaces | |
| USB 3.2 Gen 1 (3.1 Gen 1) Type-A ports quantity | 4 |
| USB 3.2 Gen 1 (3.1 Gen 1) Type-C ports quantity | 1 |
| USB 3.2 Gen 2 (3.1 Gen 2) Type-A ports quantity | 0 |
| USB 3.2 Gen 2 (3.1 Gen 2) Type-C ports quantity | 0 |
| Thunderbolt 3 ports quantity | 0 |
| HDMI version | 2.0 |
| USB 2.0 ports quantity | 0 |
| Microphone in | Yes |
| Headphone outputs | 1 |
| HDMI ports quantity | 1 |
| Ethernet LAN (RJ-45) ports | 1 |
| DisplayPorts quantity | 1 |
| DisplayPort version | 1.4 |
| Technical details | |
| Product type | Mini PC |
| Trusted Platform Module (TPM) | Yes |
| Product colour | Black |
| Chassis type | Mini PC |
| Audio system | High Definition Audio |
| Performance | |
| Trusted Platform Module (TPM) version | 2.0 |
| Software | |
| Operating system architecture | 64-bit |
| Compatible operating systems | Windows 11 IoT Enterprise |
| Operating system installed | Windows 11 IoT Enterprise |
| Power | |
| Power consumption (typical) | 80.7 W |
| Power consumption (standby) | 2.9 W |
| Operational conditions | |
| Storage temperature (T-T) | -10 - 50 °C |
| Operating relative humidity (H-H) | 10 - 95% |
| Storage relative humidity (H-H) | 10 - 95% |
| Operating temperature (T-T) | 0 - 45 °C |
| Weight & dimensions | |
| Package width | 260 mm |
| Package depth | 72 mm |
| Package height | 192 mm |
| Width | 119 mm |
| Depth | 180 mm |
| Height | 30 mm |
| Package weight | 957 g |
| Weight | 600 g |
| Packaging content | |
| Display included | No |
