HP OmniBook 7 AI 16-ay0003na 16" Core Ultra 5 225H 16GB 1TB SSD Laptop

The HP OmniBook 7 AI 16-ay0003na handles everyday computing with ease — Core Ultra 5 225H, 16GB RAM and 1TB SSD in a portable design.

AI performance and portability with a brilliant 16” display^[5].
Tough enough to meet demanding US military-grade standard testing^[1], HP OmniBook 7 16 AI PC delivers durability, performance, and portability, powered by the latest AI-enhanced Intel Core™ Ultra Processor^[2] and a brilliant 16” display^[5].

Specifications

Design
Colour name	Glacier silver
Product type	Laptop
Market positioning	Premium
Form factor	Clamshell
Product colour	Silver
Original brand name	HP
Country of origin	China, Thailand
Display
HD type	2K
Panel type	IPS
Display brightness	300 cd/m²
Display diagonal (metric)	40.6 cm
Touchscreen	No
Display resolution	1920 x 1200 pixels
Display diagonal	40.6 cm (16")
Anti-glare screen	Yes
Display bezel technology	Micro-Edge
sRGB coverage (typical)	62.5%
RGB colour space	sRGB
Colour gamut	62.5%
Native aspect ratio	16:10
Processor
Processor generation	Intel Core Ultra (Series 2)
Processor cache type	L3
Processor cache	18 MB
Processor model	225H
Processor boost frequency	4.9 GHz
Processor cores	14
Processor threads	14
Motherboard chipset	Intel SoC
Processor manufacturer	Intel
Processor family	Intel Core Ultra 5
Processor base power	28 W
Maximum turbo power	115 W
Efficient-core base frequency	1.3 GHz
Performance-core base frequency	1.7 GHz
Efficient-core Max Turbo Frequency	4.3 GHz
Performance-core Max Turbo Frequency	4.9 GHz
Performance cores	4
Efficient cores	8
Low Power Efficient-core Base Frequency	700 MHz
Low Power Efficient-core Max Turbo Frequency	2.5 GHz
Low Power Efficient-cores	2
Neural processor unit (NPU)
Neural processor unit (NPU)	Intel AI Boost
Sparsity support	Yes
Windows Studio effects support	Yes
AI software frameworks supported by NPU	DirectML, OpenVINO, Windows ML, ONNX RT, WebNN
Total processor performance up to	83 TOPs
NPU performance up to	13 TOPs
GPU performance up to	63 TOPs
Memory
Memory form factor	On-board
Internal memory	16 GB
Memory layout (slots x size)	Not available
Internal memory type	DDR5-SDRAM
Memory clock speed	5600 MHz
Memory slots (available)	0
Maximum internal memory	16 GB
Storage
SSD form factor	M.2
Storage media	SSD
Optical drive type	No
Number of SSDs installed	1
SSD capacity	1 TB
SSD interface	PCI Express 4.0
Total storage capacity	1 TB
Total SSDs capacity	1 TB
NVMe	Yes
Graphics
Discrete graphics card	No
On-board graphics card family	Intel Arc Graphics
On-board graphics card	Yes
On-board graphics card model	Intel Arc 130T
Discrete graphics card model	Not available
On-board GPU manufacturer	Intel
Audio
Number of microphones	2
Audio system	DTS:X Ultra
Built-in speaker(s)	Yes
Number of built-in speakers	2
Built-in microphone	Yes
Camera
Front camera	Yes
Front camera resolution (numeric)	5 MP
Infrared (IR) camera	Yes
Network
Mobile network connection	No
Top Wi-Fi standard	Wi-Fi 6E (802.11ax)
WLAN controller model	Intel Wi-Fi 6E AX211
Wi-Fi	Yes
Wi-Fi standards	Wi-Fi 6E (802.11ax)
Bluetooth	Yes
Bluetooth version	5.3
Antenna type	2x2
WLAN controller manufacturer	Intel
Ports & interfaces
USB 3.2 Gen 1 (3.1 Gen 1) Type-A ports quantity	1
USB 3.2 Gen 1 (3.1 Gen 1) Type-C ports quantity	0
USB 3.2 Gen 2 (3.1 Gen 2) Type-A ports quantity	1
USB 3.2 Gen 2 (3.1 Gen 2) Type-C ports quantity	1
USB Type-C DisplayPort Alternate Mode	Yes
USB Sleep-and-Charge ports	2
USB Sleep-and-Charge	Yes
USB 2.0 ports quantity	0
HDMI ports quantity	1
HDMI version	2.1
Microphone in	Yes
Combo headphone/mic port	Yes
USB Power Delivery (USB PD)	Yes
Thunderbolt 4 ports quantity	1
USB4 Gen 3x2 ports quantity	1
Intel® Thunderbolt 4	Yes
Keyboard
Pointing device	Touchpad
Numeric keypad	Yes
Full-size keyboard	Yes
Keyboard backlit	Yes
Keyboard colour name	soft grey
Software
Trial software	100 GB Dropbox storage for 3 months
Pre-installed software	Poly Camera Pro, 1 month trial for new Microsoft 365 customers, McAfee Online Protection 30-day trial; 1-month Adobe free trial offer; PC Game Pass 3-month trial
Operating system installed	Windows 11 Home
Technical details
Intel® Turbo Boost Technology	Yes
Supplied AC adapter type	Sandblasted anodized finish
Sustainable technologies and materials	Ocean-bound plastic in speaker enclosure(s) and bezel; Recycled metal in cover, keyboard frame, base and hinge cap(s); Keyboard keycaps and scissors contain post-consumer recycled plastic
Sustainability compliance	Yes
Sustainability certificates	ENERGY STAR, EPEAT, EPEAT Gold
General Product Safety Regulation (GPSR) URL	https://support.hp.com/us-en/document/ish_6126692-6126777-16?openCLC=true ; HP REG 23010, 08028 Barcelona, Spain ; reg@hp.com
HP GTIN (EAN/UPC)	199251075308
Brand-specific features
HP Security tools	Mic mute key; Camera privacy shutter; Trusted Platform Module (Firmware TPM) support
HP Software provided	HP Support Assistant; HP Connection Optimizer; HP Enhanced Lighting
HP Audio Boost	Yes
HP speaker type	HP Dual Speakers
HP Imagepad	Yes
HP segment	Home
HP Artificial Intelligence	AI PC
Battery
Battery technology	Lithium Polymer (LiPo)
Number of battery cells	4
Battery life (max)	13.25 h
Battery capacity	70 Wh
Continuous video playback time	21.75 h
Fast charging	Yes
Fast charging time (50%)	30 min
Power
AC adapter power	100 W
AC adapter frequency	50 - 60 Hz
AC adapter input voltage	100 - 240 V
USB Type-C charging port	Yes
Security
Password protection	Yes
Trusted Platform Module (TPM)	Yes
Password protection type	BIOS, Power on
Sustainability
Total carbon footprint (kg of CO2e)	150
Weight & dimensions
Width	357.8 mm
Depth	254.8 mm
Height	15 mm
Weight	1.91 kg
Packaging data
Package width	80 mm
Package height	303 mm
Package depth	423 mm
AC adapter included	Yes
Carbon footprint
Total carbon emissions, w/o use phase (kg of CO2e)	9
Carbon emissions, manufacturing (kg of CO2e)	131
Carbon emissions, logistics (kg of CO2e)	7
Carbon emissions, end-of-life (kg of CO2e)	0.8
Packaging content
Keyboard included	Yes
Other features
UNSPSC-code	43211503

Downloads

• Datasheet (PDF)
