Gigabyte P650G PCIE 5.1 Power Supply - PCIe 5.1, 80 PLUS Silver, 120mm Fan, ATX 3.1
Gigabyte P650G PCIE 5.1 Power Supply - PCIe 5.1, 80 PLUS Silver, 120mm Fan, ATX 3.1
Regular price
£47.01 GBP
Regular price
Sale price
£47.01 GBP
Taxes included.
Quantity
Couldn't load pickup availability
Reliable power for your system: the Gigabyte P650G PCIE 5.1 Power — wattage and connector details are in the spec table.
Ensure reliable and efficient power delivery with GIGABYTE power supplies. Designed for peak performance and durability, our PSUs offer stable and consistent energy to power your high-performance systems. With advanced protections and high-quality components, GIGABYTE power supplies provide the confidence you need for seamless, uninterrupted computing experiences.
Specifications
| Cooling | |
|---|---|
| Fan diameter | 12 cm |
| Number of fans | 1 fan(s) |
| Fan location | Top |
| Cooling type | Active |
| Performance | |
| On/off switch | Yes |
| Power supply unit (PSU) form factor | ATX |
| 80 PLUS certification | 80 PLUS Gold |
| Purpose | PC |
| ATX version | 3.1 |
| Mean time between failures (MTBF) | 100000 h |
| Bearing technology | HYB |
| Design | |
| Product colour | Black |
| Power | |
| Total power | 650 W |
| Maximum input current (@220V) | 6 A |
| Power Good signal delay range | 100 - 150 ms |
| AC input voltage | 100 - 240 V |
| AC input frequency | 50/60 Hz |
| Input current | 10 - 6 A |
| Power Factor Correction (PFC) type | Active |
| Maximum input current (@110V) | 10 A |
| Combined power (+3.3V) | 90 W |
| Combined power (+12V) | 650 W |
| Combined power (+5V) | 650 W |
| Combined power (-12V) | 3.6 W |
| Combined power (+5Vsb) | 15 W |
| Max output current (+3.3V) | 18 A |
| Max output current (+12V) | 54.2 A |
| Max output current (+5V) | 18 A |
| Max output current (-12V) | 0.3 A |
| Max output current (+5Vsb) | 18 A |
| Power protection features | Over power, Overcharge, Short circuit, Under voltage |
| Ports & interfaces | |
| Motherboard power cable length | 60 cm |
| SATA power cable length | 120,500 mm |
| Peripheral (Molex) power cable length | 150 mm |
| PCI Express power cable length | 50 cm |
| CPU power cable length | 60 cm |
| Motherboard power connector | 20+4 pin ATX |
| Number of SATA power connectors | 6 |
| Peripheral (Molex) power connectors (4-pin) | 3 |
| PCI Express power connectors (6+2 pin) | 2 |
| CPU P4 connector (4-pin) | 1 |
| CPU power connector (4+4 pin) | Yes |
| Floppy disk drive connector | Yes |
| ATX power connector (20+4 pin) | Yes |
| Cabling type | Non-Modular |
| Weight & dimensions | |
| Width | 140 mm |
| Depth | 150 mm |
| Height | 86 mm |
| Weight | 1.76 kg |
| Packaging data | |
| Package depth | 110 mm |
| Package width | 260 mm |
| Package height | 180 mm |
| Package type | Box |
| Package weight | 1.92 kg |
