Equip Wireless 1D Laser Barcode Scanner, with Stand

Speed up your checkout and stock-take with the Equip — scan engine and connectivity details are below.

The Equip Wireless 1D Laser Barcode Scanner with Stand is a versatile and efficient scanning solution for businesses. This device, designed for various applications, including retail and inventory management, offers the flexibility of wireless operation and the convenience of a stand for hands-free use.

With wireless capabilities, it provides freedom of movement, making it an ideal choice for scanning barcodes on products, shelves, or inventory. The included stand enhances productivity, particularly in busy retail or warehouse settings.

This 1D laser barcode scanner offers quick and precise barcode reading, simplifying data capture and reducing errors. Its wireless connectivity ensures seamless integration with your systems. This scanner streamlines operations, improves inventory accuracy, and enhances customer service, making it a cost-effective solution for businesses. It's a reliable tool for organizations seeking an efficient way to manage 1D barcoded information while maintaining flexibility and convenience.

Specifications

Scanning
Scanner resolution	4 mm
Type	Handheld bar code reader
Linear (1D) barcodes supported	Codabar, Code 11, Code 128, Code 39, Code 93, EAN 128, EAN-13, EAN-8, GS1 DataBar, ISBN, ISSN, Interleaved 2 of 5, UPC-A, UPC-E
2D (matrix & stacked) barcodes supported	Not supported
Working distance	70 cm
Wavelength	650 nm
Sensor type	LED
Scanner type	1D
Read rate (max)	200 reads/s
Maximum scan width	30 cm
Trigger mode	Auto-induction, Continuous, Manual
Depth of field range	7.5 cm
Ports & interfaces
Connectivity technology	Wireless
Operating frequency	2400 MHz
Cable length	1.8 m
Standard interfaces	RF Wireless
Performance
Protection features	Drop proof, Water resistant
Housing material	Acrylonitrile butadiene styrene (ABS)
International Protection (IP) code	IP54
Product colour	Black
Country of origin	China
Power
Power source type	Battery
Number of batteries supported	1
Battery life	20 h
Battery voltage	3.7 V
Input voltage	5 V
Battery type	Built-in battery
Battery technology	Lithium-Ion (Li-Ion)
Battery capacity	1500 mAh
Weight & dimensions
Width	72 mm
Depth	101 mm
Height	175 mm
Weight	190 g
Package width	150 mm
Package depth	207 mm
Package height	100 mm
Package weight	465 g
Technical details
Windows operating systems supported	Windows 10, Windows 10 Education, Windows 10 Education x64, Windows 10 Enterprise, Windows 10 Enterprise x64, Windows 10 Home, Windows 10 Home x64, Windows 10 IOT Core, Windows 10 IoT Enterprise, Windows 10 Pro, Windows 10 Pro x64, Windows 10 x64, Windows 11, Windows 11 Enterprise, Windows 7, Windows 7 Enterprise, Windows 7 Enterprise x64, Windows 7 Home Basic, Windows 7 Home Basic x64, Windows 7 Home Premium, Windows 7 Home Premium x64, Windows 7 Professional, Windows 7 Professional x64, Windows 7 Starter, Windows 7 Starter x64, Windows 7 Ultimate, Windows 7 Ultimate x64, Windows 7 x64, Windows XP, Windows XP Home, Windows XP Home x64, Windows XP Professional, Windows XP Professional x64
Mobile operating systems supported	Android, iOS
Sustainability compliance	Yes
Harmonized System (HS) code	8471900090
Compliance certificates	CE, RoHS
Packaging data
Charging base	Yes
Cables included	USB
Stand included	Yes
Receiver type	Nano receiver
Receiver included	Yes
Operational conditions
Storage temperature (T-T)	-40 - 85 °C
Operating temperature (T-T)	-20 - 60 °C
Operating relative humidity (H-H)	5 - 95%
Logistics data
Products per master (outer) case	30 pc(s)
Master (outer) case width	440 mm
Master (outer) case gross weight	15.5 kg
Master (outer) case length	485 mm
Master (outer) case height	525 mm
Other features
Quick start guide	Yes
Linux operating systems supported	Yes

Downloads

• Datasheet (PDF)
