Epson EB-L265F Projector

Fill the wall with the Epson EB-L265F — brightness, resolution and throw details are in the spec table below.

Digital signage projector
The EB-L265F is a cost-effective laser display solution with easy and flexible installation. It can be installed on floor, wall or ceiling (including on a lighting track). A single projector can create a display of up to 310" with a range of flexible content source options including local content playback support (via a memory card), Miracast wireless connectivity and HDMI.

Innovative and cost effective
Epson's advanced laser technology is bright, robust and reliable for a flexible and easy to use digital signage solution. It offers bright and vivid colours in a cost-effective solution capable of creating large displays or even projecting onto 3D objects.

Flexible display options
The EB-L265F enables scalable display sizes of up to 310 inches with a single projector - even larger when edge-blending 2 units. Full HD, 4,600 lumen brightness and 3LCD technology offer bright colours and high quality - perfect for creating engaging and informative displays, even in bright spaces.
It can be mounted wherever needed - wall, floor or ceiling (inc.on a lighting track) with optional accessories. A white model is also available (EB-L260F) to ensure the projector is as discrete as possible.

Create dynamic content
Epson offers free apps for content creation (Epson Creative Projection & Epson Projector Content Management). Content can be played directly from USB (including playlists, videos, and signage content) using the built-in playback feature. Users can even upload and playback content wirelessly with built-in Wi-Fi and Miracast functionality.

Low maintenance and high reliability
Up to 20,000 hours maintenance-free use using a laser light source with a 5 year warranty make this a cost-effective fit-and-forget display solution you can rely on.

Specifications

Projector
Number of colours	1.07 billion colours
Projector native resolution	1080p (1920x1080)
Native aspect ratio	16:9
Screen size compatibility	787.4 - 7874 mm (31 - 310")
Contrast ratio (typical)	2500000:1
Zoom ratio	1:1.62
Zoom capability	Yes
Projector brightness (economic mode)	3200 ANSI lumens
Matrix size	1.57 cm (0.62")
Keystone correction, vertical	-30 - 30°
Keystone correction, horizontal	-30 - 30°
Projection technology	3LCD
Projector brightness	4600 ANSI lumens
Zoom type	Manual
Smart projector	No
Lamps
Light source type	Laser
Service life of light source	20000 h
Service life of light source (economic mode)	30000 h
Lens system
Focus	Manual
Focal length range	18.2 - 29.1 mm
Aperture range (F-F)	1.51 - 1.77
Throw ratio	1,32 - 2,12:1
Video
Video colour modes	Blackboard, Cinema, Dynamic, Multi-projection, Presentation, sRGB
Analog signal format system	Not supported
Full HD	Yes
3D	Yes
Audio
Built-in speaker(s)	Yes
RMS rated power	16 W
Ports & interfaces
VGA (D-Sub) ports quantity	3
HDMI ports quantity	2
USB 2.0 ports quantity	1
Composite video in	1
Headphone outputs	3
Serial interface type	RS-232C
DVI port	No
Component video (YPbPr/YCbCr) in	0
Service port type	USB Type-B
Network
Smart TV	No
Ethernet LAN	Yes
Wi-Fi	Yes
Wi-Fi standards	802.11a, 802.11b, 802.11g, Wi-Fi 4 (802.11n), Wi-Fi 5 (802.11ac)
Storage
Card reader integrated	No
Sound emission
Noise level	37 dB
Noise level (economic mode)	27 dB
Technical details
Product colour	Black
HDCP	Yes
Performance
Market positioning	Presentation
Features
Interactive	No
Design
Cable lock slot type	Kensington
Cable lock slot	Yes
Placement	Ceiling, Floor, Wall
Display
Built-in display	No
Power
AC input voltage	220 - 240 V
AC input frequency	50/60 Hz
Power source	AC
Power consumption (typical)	199 W
Power consumption (economy mode)	144 W
Operational conditions
Operating relative humidity (H-H)	20 - 80%
Storage temperature (T-T)	-10 - 60 °C
Storage relative humidity (H-H)	10 - 90%
Weight & dimensions
Weight	4.2 kg
Packaging content
Remote control included	Yes
Cables included	AC, HDMI
Batteries included	Yes
