Epson EB-760Wi Projector

Fill the wall with the Epson EB-760Wi — brightness, resolution and throw details are in the spec table below.

Agile USTi laser display
Whatever the size of class or meeting room, unrestricted and interactive presentations are possible with this bright, compact and affordable touch-display solution.

The EB-760Wi's vibrant image, scalable up to 100", is clearly visible from any angle and from a distance, and content can be easiliy shared or streamed directly from multiple devices for the perfect collaborative experience.


The EB-760Wi is a step up from the EB-760W, with added interactive features.


Interactive technology enables two digital pens to be used simultaneously on the display (finger touch available through optional accessory FT01). Presentations can be controlled and brought to life with on-screen annotations, while a variety of convenient built-in tools support productivity. An optional Epson visualiser camera can be controlled via the display, projecting documents or objects from a desk for everyone to see in incredible HD detail.


The ultra short throw lens allows safe, discreet positioning above the display, enabling presenters free access to interact without casting shadows.


With a 4,100 lumens laser-light source, combined with 3LCD technology, it produces a large, bright and vibrant display up to 100", visibly clear from all angles and at a distance.


Versatile wired and wireless connectivity options, including screen mirroring via Miracast™, allow participants to effortlessly share content from their PCs or mobile devices.


Unlike a flat-panel display, there is no heavy, breakable, glass panel to create disruptive, reflected blind spots from certain angles, and presenters are not subjected to LCD panel direct blue light radiation, believed to damage eyes.

Specifications

Projector
Number of colours	1.07 billion colours
Projector native resolution	WXGA (1280x800)
Native aspect ratio	16:10
Screen size compatibility	1346.2 - 2540 mm (53 - 100")
Contrast ratio (typical)	2500000:1
Zoom ratio	1.35:1
Projector brightness (economic mode)	2100 ANSI lumens
Matrix size	1.5 cm (0.59")
Keystone correction, vertical	-3 - 3°
Keystone correction, horizontal	-3 - 3°
Projection technology	3LCD
Projector brightness	4100 ANSI lumens
Smart projector	No
Lamps
Light source type	Laser
Service life of light source	20000 h
Service life of light source (economic mode)	30000 h
Lens system
Fixed focal length	3.7 mm
Focus	Manual
Throw ratio	0.27 - 0.37:1
F-number (relative aperture)	1.6
Video
Analog signal format system	Not supported
Full HD	No
3D	No
Audio
Built-in speaker(s)	Yes
RMS rated power	16 W
Ports & interfaces
VGA (D-Sub) ports quantity	3
HDMI ports quantity	3
USB 2.0 ports quantity	2
Composite video in	1
Headphone outputs	3
Microphone in	Yes
Serial interface type	RS-232C
DVI port	No
Component video (YPbPr/YCbCr) in	0
Service port type	USB Type-B
Network
Smart TV	No
Ethernet LAN	Yes
Ethernet LAN data rates	10,100 Mbit/s
Wi-Fi	Yes
Wi-Fi standards	802.11a, 802.11b, 802.11g, Wi-Fi 4 (802.11n), Wi-Fi 5 (802.11ac)
Miracast	Yes
Storage
Card reader integrated	No
Sound emission
Noise level	37 dB
Noise level (economic mode)	27 dB
Technical details
Product colour	White
On Screen Display (OSD)	Yes
Air filter	Yes
Performance
Market positioning	Presentation
Features
Interactive	Yes
Design
Cable lock slot type	Kensington
Cable lock slot	Yes
Placement	Ceiling, Desktop, Wall
Display
Built-in display	No
Power
AC input voltage	100 - 240 V
AC input frequency	50/60 Hz
Power source	AC
Power consumption (typical)	197 W
Power consumption (economy mode)	141 W
Operational conditions
Operating relative humidity (H-H)	20 - 80%
Storage relative humidity (H-H)	-10 - 90%
Weight & dimensions
Weight	6 kg
Width	356 mm
Depth	395 mm
Height	133 mm
Packaging content
Remote control included	Yes
Cables included	AC, USB
Batteries included	Yes
Interactive pen included	Yes
