DELL Pro Max 16 Premium MA16250 16" Core Ultra 9 285H 64GB 1TB SSD Laptop

The DELL Pro Max 16 Premium MA16250 handles everyday computing with ease — Core Ultra 9 285H, 64GB RAM and 1TB SSD in a portable design.

Unstoppable power. Modern design.
Empower your creativity with the thin, light 16-inch laptop that elevates every task effortlessly with exceptional battery life, Intel® Core™ Ultra processors, NVIDIA graphics, and advanced on-device AI.

Specifications

Design
Colour name	Magnetite
Product type	Mobile workstation
Form factor	Clamshell
Product colour	Black
Intel® vPro™ Platform Eligibility	Yes
Display
HD type	Full HD+
Pixel density	142 ppi
Panel type	WVA
Display brightness	500 cd/m²
Display response rise/fall	35 ms
Contrast ratio (typical)	1500:1
Touchscreen	No
Display resolution	1920 x 1200 pixels
Display diagonal	40.6 cm (16")
Anti-glare screen	Yes
Maximum refresh rate	120 Hz
RGB colour space	DCI-P3
Colour gamut	100%
Native aspect ratio	16:10
Processor
Processor generation	Intel Core Ultra (Series 2)
Processor cache	24 MB
Processor model	285H
Processor boost frequency	5.4 GHz
Processor cores	16
Processor threads	16
Motherboard chipset	Intel SoC
Processor manufacturer	Intel
Processor family	Intel Core Ultra 9
Processor base power	45 W
Maximum turbo power	115 W
Efficient-core base frequency	2.7 GHz
Performance-core base frequency	2.9 GHz
Efficient-core Max Turbo Frequency	4.5 GHz
Performance-core Max Turbo Frequency	5.4 GHz
Performance cores	6
Efficient cores	8
Low Power Efficient-core Base Frequency	1000 MHz
Low Power Efficient-core Max Turbo Frequency	2.5 GHz
Low Power Efficient-cores	2
Neural processor unit (NPU)
Neural processor unit (NPU)	Intel AI Boost
Sparsity support	Yes
Windows Studio effects support	Yes
AI software frameworks supported by NPU	DirectML, OpenVINO, Windows ML, ONNX RT, WebNN
Total processor performance up to	99 TOPs
NPU performance up to	13 TOPs
GPU performance up to	77 TOPs
Memory
Memory form factor	On-board
Internal memory	64 GB
Internal memory type	LPDDR5x-SDRAM
Maximum internal memory	64 GB
Memory data transfer rate	8400 MT/s
Storage
SSD form factor	M.2
Storage media	SSD
Optical drive type	No
Number of SSDs installed	1
SSD capacity	1 TB
SSD interface	PCI Express 4.0
Card reader integrated	Yes
Compatible memory cards	SD, SDHC, SDXC
Total storage capacity	1 TB
SSD memory type	TLC
Total SSDs capacity	1 TB
Self-Encrypting Drive (SED)	Yes
NVMe	Yes
Graphics
Discrete graphics card	Yes
Discrete graphics card memory	8 GB
On-board graphics card family	Intel Arc Graphics
On-board graphics card	Yes
On-board graphics card model	Intel Arc 140T
Discrete graphics card model	NVIDIA RTX PRO 2000 Blackwell
Discrete graphics memory type	GDDR7
Discrete GPU manufacturer	NVIDIA
On-board GPU manufacturer	Intel
Audio
Audio chip	Cirrus Logic CS42L43
Audio system	Dolby Atmos
Number of built-in speakers	4
Built-in microphone	Yes
Camera
Front camera	Yes
Front camera resolution (numeric)	8 MP
Front camera resolution	2560 x 1440 pixels
Video capturing speed	30 fps
Infrared (IR) camera	Yes
Network
Mobile network connection	No
Top Wi-Fi standard	Wi-Fi 7 (802.11be)
WLAN controller model	Intel Wi-Fi 7 BE201
Wi-Fi standards	802.11a, 802.11ad, 802.11b, 802.11g, Wi-Fi 5 (802.11ac), Wi-Fi 7 (802.11be)
Ethernet LAN	No
Bluetooth	Yes
WWAN	Not installed
MIMO type	Multi User MIMO
MIMO	Yes
WLAN controller manufacturer	Intel
Wi-Fi band	Tri-band (2.4 GHz / 5 GHz / 6 GHz)
Ports & interfaces
USB 3.2 Gen 1 (3.1 Gen 1) Type-A ports quantity	0
USB 3.2 Gen 1 (3.1 Gen 1) Type-C ports quantity	0
USB Type-C DisplayPort Alternate Mode	Yes
USB 2.0 ports quantity	0
HDMI ports quantity	1
HDMI version	2.1
Ethernet LAN (RJ-45) ports	0
Combo headphone/mic port	Yes
USB Power Delivery (USB PD)	Yes
Thunderbolt 4 ports quantity	1
Intel® Thunderbolt 4	Yes
Thunderbolt 5 ports quantity	2
Intel® Thunderbolt 5	Yes
Performance
Ambient light sensor	Yes
Accelerometer	Yes
Hall sensor	Yes
Keyboard
Pointing device	Touchpad
Numeric keypad	No
Spill-resistant keyboard	Yes
Keyboard backlit	Yes
Keyboard language	UK English
Copilot key	Yes
Software
Operating system architecture	64-bit
Trial software	Activate Your Microsoft 365 For A 30 Day Trial
Operating system installed	Windows 11 Pro
Brand-specific features
Brand specific technologies	Express Charge Boost capable, TNR, ExpressSign-In, Battery-saving Mini-LED, Zero-lattice Keyboard
Battery
Battery technology	Lithium-Ion (Li-Ion)
Number of battery cells	6
Battery capacity	96 Wh
Battery recharge time	3 h
Battery voltage	11.7 V
Fast charging	Yes
Battery weight	351 g
Power
USB charging voltage	20,5,9,15 V
USB Type-C charging port	Yes
USB Type-C required charging power (min)	100 W
USB Type-C required charging power (max)	100 W
Security
Cable lock slot type	Wedge
Trusted Platform Module (TPM)	Yes
Fingerprint reader	Yes
Cable lock slot	Yes
Trusted Platform Module (TPM) version	2.0
Operational conditions
Operating temperature (T-T)	0 - 35 °C
Storage temperature (T-T)	-40 - 65 °C
Operating relative humidity (H-H)	10 - 90%
Storage relative humidity (H-H)	0 - 95%
Operating altitude	-15.2 - 3048 m
Non-operating altitude	-15.2 - 10668 m
Operating shock	110 G
Non-operating shock	160 G
Operating vibration	0.66 G
Non-operating vibration	1.3 G
Sustainability
Total carbon footprint (kg of CO2e)	175
Weight & dimensions
Width	353.8 mm
Depth	240.3 mm
Height (front)	2.08 cm
Height (rear)	2.08 cm
Weight	2.19 kg
Packaging data
AC adapter included	No
Carbon footprint
PAIA version	GaBi version 1, 2025
Carbon emissions, energy usage (kg of CO2e)	30.1
Carbon emissions, manufacturing (kg of CO2e)	136.5
Carbon emissions, logistics (kg of CO2e)	6.48
Carbon emissions, end-of-life (kg of CO2e)	1.93
