be quiet! LIGHT WINGS LX 140mm PWM high-speed Computer case Fan 14 cm Black 1 pc(s) Cooling

Keep temperatures in check with the be quiet! LIGHT WINGS LX 140mm — fitment and noise details are in the spec table.

Great performance and impressive lighting
The Light Wings LX 140mm PWM high-speed boasts optimized fan blades and an illuminated impeller for great performance and lighting.

Specifications

Performance
Suitable location	Computer case
Fan connector	4-pin
Pulse-width modulation (PWM) support	Yes
Rotational speed (max)	1800 RPM
Bearing type	Rifle bearing
Noise level (high speed)	30.5 dB
Type	Fan
Fan diameter	14 cm
Maximum airflow	75.3 cfm
Maximum air pressure	2.45 mmH2O
Airflow	127.9 m³/h
Number of fans	1 fan(s)
Mean time between failures (MTBF)	60000 h
Quantity per pack	1 pc(s)
Number of fan blades	9
Design
Illumination colour	Multi
Product colour	Black
Cable length	0.5 m
Illumination LED	Yes
Number of LEDs	16
Display type	Not applicable
LED connector type	3-pin
Technical details
Compliance certificates	CE, RoHS, UKCA, WEEE
Power
Rated voltage	12 V
Voltage	5 - 13.2 V
Maximum current	0.45 A
Fan power consumption	5.4 W
Fan voltage	12 V
Fan current	0.18 A
Weight & dimensions
Package depth	184 mm
Package width	142 mm
Package height	27 mm
Width	140 mm
Package weight	210 g
Depth	25 mm
Height	140 mm
Weight	169 g
Packaging data
Package type	Box
Packaging content
Screws included	Yes
Number of screws	4
Logistics data
Shipping (inner) case width	37.8 cm
Shipping (inner) case length	49.4 cm
Shipping (inner) case height	33 cm
Shipping (inner) case gross weight	16.1 kg
Products per shipping (inner) case	72 pc(s)

Downloads

• Datasheet (PDF)
