ATEN CS19208 KVM switch Rack mounting Black

Control multiple machines from one keyboard, monitor and mouse with the ATEN CS19208.

The ATEN CS19208 8-Port USB 3.0 4K DisplayPort KVM Switch can effectively access and control up to 8 DisplayPort computers from a single USB keyboard, USB mouse, and monitor console. With its dual interface console, users can choose between DisplayPort/HDMI video output supporting high video quality up to 4K DCI (4096 x 2160 @ 60Hz), presenting crystal-clear visuals.

To meet the needs of easy expansion and flexibility, the CS19208 can be cascaded to two levels to control up to 128 computers from a single console. Furthermore, the CS19208 supports multi-display function by stacking up to eight CS19208 units to compare and analyze information on 8 monitors at most, which substantially streamlines the working environment.

With two patented ATEN technology – Video DynaSync™ and EDID Expert™ , the CS19208 can optimize display resolution, accelerate switching between ports and power up smoothly while eliminating boot-up display problems.

Besides, the CS19208 comes with a built-in USB 3.1 Gen 1 hub delivering data transfer rates up to 5 Gbps, allowing users to speed up operations and share USB peripherals instantly. For user-friendly port selection methods, the CS19208 offers pushbuttons, hotkeys, RS-232 commands, and OSD with newly-designed UI, bringing effortless and intuitive operations.

To eliminate security concern, a two-level password authorization is available to enhance security protection for accessing and controlling computers. Consolidating these advantageous functionalities, the CS19208 is ideal for server room/computer room management applied in industries with requirements for high-quality images and multitasking, such as Enterprise, Government, Production, Telecom, Finance, Medical Healthcare, Industrial Automation, etc.

Specifications

Technical details
Product colour	Black
Rack mounting	Yes
LED indicators	Yes
Video
HD type	4K Ultra HD
Video bandwidth	60 Hz
Maximum resolution	4096 x 2160 pixels
Ports & interfaces
Console USB ports quantity	6
Console ports	3.5mm headphone, DisplayPort, HDMI, USB A
DisplayPorts quantity	8
Number of computers controlled	128
Keyboard port type	USB
Mouse port type	USB
Video port type	DisplayPort
DC-in jack	Yes
USB 3.2 Gen 1 (3.1 Gen 1) Type-B ports quantity	8
USB 3.2 Gen 1 (3.1 Gen 1) Type-A hub ports quantity	2
Performance
Firmware upgradeable	Yes
Auto scan delay (max)	255 s
Design
Housing material	Metal
Power
Power consumption (typical)	18.44 W
Operational conditions
Operating temperature (T-T)	0 - 40 °C
Storage temperature (T-T)	-20 - 60 °C
Operating relative humidity (H-H)	0 - 80%
Weight & dimensions
Width	214.3 mm
Depth	432.4 mm
Height	44 mm
Weight	3.11 kg
Packaging content
Cables included	Audio (3.5mm), DisplayPort, USB
Manual	Yes
