ATEN

ATEN CS1716A KVM switch Rack mounting Black

£459.73 GBP

Sale Sold out

Taxes included.

Condition New

Control multiple machines from one keyboard, monitor and mouse with the ATEN CS1716A.

The CS1716A KVM switch is a control unit that allows access to multiple computers from a single PS/2 or USB console (keyboard, mouse, and monitor). A single CS1716A can control up to 16 computers. As many as 31 additional switches can be daisy-chained to each other, so that up to 512 computers can all be controlled from a single keyboard-monitor-mouse console. Additionally, a front panel USB port is available for each computer to access any peripherals connected to it on a one-at-a-time basis.

Specifications

Ports & interfaces
Console USB ports quantity	1
Console ports	USB A, VGA (D-Sub)
Number of computers controlled	512
Keyboard port type	USB, PS/2
Mouse port type	USB, PS/2
Video port type	VGA
VGA (D-Sub) ports quantity	17
DC-in jack	Yes
Performance
DDC2B support	No
Daisy chain	Yes
Firmware upgradeable	Yes
Hot-Plug support	Yes
Maximum resolution	2048 x 1536 pixels
Scan interval	1,255 s
Technical details
Product colour	Black
Rack mounting	Yes
Push button	Yes
On Screen Display (OSD)	Yes
LED indicators	Yes
Hot keys	Yes
Compliance certificates	RoHS
Design
Rack capacity	1U
Housing material	Metal
Display
Built-in display	No
Power
Power source	DC
Power consumption (typical)	6.6 W
Input voltage	5.3 V
System requirements
Windows operating systems supported	Yes
Linux operating systems supported	Yes
Mac operating systems supported	Yes
Other operating systems supported	Yes
Operational conditions
Operating temperature (T-T)	0 - 50 °C
Storage temperature (T-T)	-20 - 60 °C
Operating relative humidity (H-H)	0 - 80%
Weight & dimensions
Width	437.2 mm
Depth	159.9 mm
Height	44 mm
Weight	2.85 kg
Packaging content
Rack mount kit	Yes
Cables included	KVM
Quick installation guide	Yes
AC adapter included	Yes
Logistics data
Harmonized System (HS) code	85176200
