ASUS Prime GeForce RTX 5060 Ti 16GB GDDR7 Graphics Card

The ASUS Prime GeForce RTX 5060 Ti brings 16GB GDDR7 graphics muscle for high-refresh gaming and GPU-accelerated creative work — see the spec table for clocks, outputs and cooling.

Primed for Power
Experience Primal performance with the Prime GeForce RTX 5060 Ti, an SFF-Ready Enthusiast GeForce Card featuring a 2.5-slot design for expansive compatibility, enhanced by a triple-fan setup for supreme airflow design for supreme cooling.

Specifications

Processor
Graphics processor family	NVIDIA
Processor boost clock speed	2617 MHz
Stream processors	4
Parallel processing technology support	Not supported
Maximum displays per videocard	4
CUDA cores	4608
CUDA	Yes
Maximum resolution	7680 x 4320 pixels
Graphics processor	GeForce RTX 5060 Ti
Processor frequency (OC mode)	2647 MHz
Memory
Discrete graphics card memory	16 GB
Data transfer rate	28 Gbit/s
Memory bus	128 bit
Graphics card memory type	GDDR7
Ports & interfaces
HDMI version	2.1b
Mini HDMI ports quantity	0
Mini DisplayPorts quantity	0
HDMI ports quantity	1
DisplayPort version	2.1b
VGA (D-Sub) ports quantity	0
DVI-I ports quantity	0
DVI-D ports quantity	0
DisplayPorts quantity	3
Interface type	PCI Express 5.0
USB Type-C ports quantity	0
Thunderbolt 3 ports quantity	0
Video
OpenGL version	4.6
HDCP	Yes
Dual Link DVI	No
Performance
NVIDIA G-SYNC	Yes
Virtual Reality (VR) ready	Yes
HDCP version	2.3
NPU performance up to	759 TOPs
Overclocked (OC) edition	Yes
Design
Number of fans	3 fan(s)
Illumination	No
Cooling type	Active
Form factor	Full-Height/Full-Length (FH/FL)
Product colour	Multicolour
Number of slots	2.5
Bracket height	Full-Height (FH)
Cooling technology	ASUS Axial-tech
SFF ready	Yes
Software
Windows operating systems supported	Yes
Power
Supplementary power connectors	1x 8-pin
Minimum system power supply	550 W
Weight & dimensions
Weight	898 g
Height	120 mm
Depth	50 mm
Length	304 mm
Packaging data
Package type	Box
Package width	405 mm
Package height	88.5 mm
Package depth	233 mm
Package weight	1.49 kg
