ASUS ExpertBook P1 PM1503CD-715X 15.6" Ryzen 7 170 16GB 512GB SSD Laptop

A dependable business machine, the ASUS ExpertBook P1 PM1503CD-715X brings Ryzen 7 170, 16GB RAM and 512GB SSD to the daily commute and the desk alike.

Elevate your efficiency, anywhere
The compact and elegant ASUS ExpertBook P1 weighs a mere 1.6kg1 with a breathtaking new design, and features exceptional efficiency to supercharge your productivity. It’s engineered to deliver superb performance powered by an up to AMD® Ryzen™ 7 processor and packs up to 1TB capacity with dual SSDs. ASUS ExpertBook P1 is also engineered to protect your privacy and business data via a built-in fingerprint sensor and integrated TPM 2.0 chip2 — your reliable, trusted traveling companion, ready to complete every task on time.

Specifications

Design
Colour name	Misty Grey
Product type	Laptop
Market positioning	Work
Housing material	Plastic
Form factor	Clamshell
Product colour	Grey
Display
HD type	Full HD
LED backlight	Yes
Display brightness	300 cd/m²
Contrast ratio (typical)	700:1
Touchscreen	No
Display resolution	1920 x 1080 pixels
Display diagonal	39.6 cm (15.6")
Anti-glare screen	Yes
Maximum refresh rate	60 Hz
RGB colour space	NTSC
Colour gamut	45%
Native aspect ratio	16:9
Processor
Processor generation	AMD Ryzen 100 Series
Processor cache type	L2 & L3
Processor frequency	3.2 GHz
Processor model	170
Processor boost frequency	4.75 GHz
Processor cores	8
Processor threads	16
L3 cache	16 MB
L2 cache	4 MB
Processor manufacturer	AMD
Processor family	AMD Ryzen™ 7
Memory
Memory form factor	SO-DIMM
Internal memory	16 GB
Internal memory type	DDR5-SDRAM
Memory slots	2x SO-DIMM
Maximum internal memory	64 GB
Storage
SSD form factor	M.2
Storage media	SSD
Optical drive type	No
Number of SSDs installed	1
SSD capacity	512 GB
SSD interface	PCI Express 4.0
Total storage capacity	512 GB
Total SSDs capacity	512 GB
NVMe	Yes
M.2 SSD size	2280 (22 x 80 mm)
Graphics
Discrete graphics card	No
On-board graphics card family	AMD Radeon
On-board graphics card	Yes
On-board graphics card model	AMD Radeon 680M
Discrete graphics card model	Not available
On-board GPU manufacturer	AMD
Audio
Audio system	Dirac
Built-in microphone	Yes
Camera
Front camera	Yes
Privacy camera	Yes
Privacy type	Privacy shutter
Front camera HD type	HD
Network
Mobile network connection	No
Top Wi-Fi standard	Wi-Fi 6 (802.11ax)
Wi-Fi standards	Wi-Fi 6 (802.11ax)
Ethernet LAN	Yes
Ethernet LAN data rates	1000 Mbit/s
Bluetooth	Yes
Bluetooth version	5.4
Antenna type	2x2
Ports & interfaces
USB 3.2 Gen 1 (3.1 Gen 1) Type-A ports quantity	2
USB 3.2 Gen 1 (3.1 Gen 1) Type-C ports quantity	0
USB 3.2 Gen 2 (3.1 Gen 2) Type-C ports quantity	2
USB Type-C DisplayPort Alternate Mode	Yes
USB 2.0 ports quantity	0
HDMI ports quantity	1
HDMI version	1.4
Ethernet LAN (RJ-45) ports	1
Combo headphone/mic port	Yes
USB Power Delivery (USB PD)	Yes
Keyboard
Pointing device	Touchpad
Numeric keypad	Yes
Software
Operating system architecture	64-bit
Trial software	1-month trial for new Microsoft 365 customers. Credit card required.
Operating system installed	Windows 11 Pro
Technical details
Sustainability certificates	Forest Stewardship Council (FSC) Recycled, TCO, ENERGY STAR, EPEAT Climate +, EPEAT Gold
Compliance certificates	REACH
Battery
Battery technology	Lithium-Ion (Li-Ion)
Number of battery cells	3
Battery capacity	50 Wh
Power
AC adapter power	65 W
AC adapter frequency	50 - 60 Hz
AC adapter input voltage	100 - 240 V
AC adapter output current	3.25 A
AC adapter output voltage	20 V
USB Type-C charging port	Yes
USB Type-C required charging power (min)	55 W
USB Type-C required charging power (max)	65 W
Security
Password protection	Yes
Cable lock slot type	Kensington
Trusted Platform Module (TPM)	Yes
Password protection type	BIOS, User, HDD
Fingerprint reader	Yes
Cable lock slot	Yes
Trusted Platform Module (TPM) version	2.0
Weight & dimensions
Width	359.5 mm
Depth	232.2 mm
Height	19.9 mm
Weight	1.81 kg
Packaging data
AC adapter included	Yes

Downloads

• Datasheet (PDF)
