ASUS EBA63 ExpertWiFi AX3000 Dual-band PoE WiFi 6 Networking

The ASUS EBA63 ExpertWiFi AX3000 Dual-band PoE is a dependable addition to any modern network installation.

ASUS ExpertWiFi EBA63 PoE Access Point
Your Business WiFi Expert Within Reach
The ASUS ExpertWiFi EBA63 is a Power over Ethernet (PoE) solution that provides fast, seamless and secure networking, with rich features tailored for small-to-midsized businesses. With its easy scalability, it can effortlessly adapt to your business network needs.

Fast, Versatile Connectivity to Accommodate All Business Scenarios
The ASUS ExpertWiFi EBA63 provides seamless connectivity for various business settings, featuring the flexible power options of PoE (Power over Ethernet) and AC adapters. By connecting to a PoE switch or PoE wired router, you can get both power and data transmission over a single Ethernet cable.

Extend Your Business Network with ASUS ExpertWiFi
ASUS ExpertWiFi networking products are designed for easy scalability to fit a variety of SMB scenarios. By integrating ExpertWiFi series products, you can extend your business network coverage and access a complete suite of ExpertWiFi’s software features to boost your business operations. You can also connect the ExpertWiFi products with ASUS AiMesh extendable routers.

*The ASUS ExpertWiFi series is compatible with ASUS AiMesh products; however, the functionality of software features is subject to the capabilities of the primary router. The availability of some ExpertWiFi features may also depend on whether the AiMesh router supports them.

Specifications

Data transmission
Ethernet LAN data rates	10,100,1000 Mbit/s
Maximum data transfer rate	2402 Mbit/s
Performance
2.4 GHz	Yes
5 GHz	Yes
Syslog	Yes
Reset button	Yes
Firmware upgradeable	Yes
Spread spectrum method	OFDMA
Frequency band	2.4 - 5 GHz
Number of users	100 user(s)
VLAN support	Yes
Networking standards	IEEE 802.11a, IEEE 802.11ac, IEEE 802.11ax, IEEE 802.11b, IEEE 802.11g, IEEE 802.11n
Internal memory	512 MB
Flash memory	256 MB
Built-in processor	Yes
Processor frequency	1.7 MHz
Features
6 GHz	No
Maximum data transfer rate (2.4 GHz)	574 Mbit/s
Maximum data transfer rate (5 GHz)	2402 Mbit/s
BeamForming	Yes
Security
Number of SSID supported	5
Security algorithms	IPSec, SSH, WPA-Enterprise, WPA-Personal, WPA2-Enterprise, WPA2-Personal, WPS
MAC address filtering	Yes
Ports & interfaces
Ethernet LAN (RJ-45) ports	1
Power
Power over Ethernet (PoE)	Yes
Input current	1.5 A
DC voltage range	12 V
Design
Placement	Ceiling, Wall
Product colour	White
LED indicators	Power
Antenna
Antenna type	Internal
Antennas quantity	4
Weight & dimensions
Width	160 mm
Depth	160 mm
Weight	426 g
Height	42 mm
Package width	262 mm
Package depth	180 mm
Package height	58 mm
Package weight	750 g
Packaging data
Quick start guide	Yes
Mounting kit	Yes
Package type	Box
Cables included	LAN (RJ-45)
AC adapter included	Yes
