ARCTIC

ARCTIC Freezer 4U-SP5 - 4U Server Cooler for AMD SP5 Cooling

£100.32 GBP

Sale Sold out

Taxes included.

Condition New

Keep temperatures in check with the ARCTIC Freezer 4U-SP5 - 4U — fitment and noise details are in the spec table.

Efficient, reliable, durable and quiet – the demands on server cooling are high. ARCTIC has developed specialised solutions for continuous operation that ensure the reliable performance of servers and workstations. Our fans deliver high performance and set new standards in energy efficiency.

Specifications

Performance
Suitable location	Processor
Fan connector	4-pin
Number of fins	62
Fins material	Aluminium
Bearing type	Dual ball bearing
Thermal Design Power (TDP)	360 W
Number of heat pipes	10
Heat pipes diameter	6 mm
Type	Air cooler
Operating temperature (T-T)	0 - 40 °C
Fan diameter	12 cm
Supported processor sockets	Socket SP5
Maximum airflow	81.04 cfm
Airflow	137.69 m³/h
Rack capacity	4U
Number of fans	2 fan(s)
Fan noise level (max)	45.3 dB
Fan static pressure	4.35 mmH2O
Fan speed (min)	300 RPM
Fan speed (max)	3300 RPM
Design
Product colour	Aluminium, Black
Cable length	0.2 m
Power
Starting voltage	3.1 V
Fan voltage	12 V
Fan current	0.29 A
Weight & dimensions
Package depth	206 mm
Package width	160 mm
Package height	141 mm
Width	147 mm
Package weight	1.56 kg
Depth	124 mm
Height	145 mm
Weight	1.51 kg
Packaging data
Package type	Box
